An End-To-End Visual Studio LightSwitch 2013 HTML5 Application

, 23 Aug 2014 CPOL 38.1K 58
Rate this:
Please Sign up or sign in to vote.
A Visual Studio 2013 LightSwitch HTML 5 Application Tutorial

Download the project from here: http://code.msdn.microsoft.com/vstudio/An-End-To-End-Visual-ef8d9a61

Live Demo: https://endtoendexample.lightswitchhelpwebsite.com/Client/default.htm (use your username and password from http://LightSwitchHelpWebsite.com)

NOTE: You can see an article on creating a report for this application at: Creating A LightSwitch HTML Report Using ActiveReports (using Parameters and Intrinsic Data)

In this article we will create an end-to-end HTML application in Visual Studio LightSwitch. The purpose is to demonstrate how LightSwitch allows you to create professional business applications that would take a developer days to create. With LightSwitch you can create such applications in under an hour.

You can download LightSwitch at: http://www.microsoft.com/visualstudio/en-us/lightswitch. Also, you must have Visual Studio 2013 (or higher) and the Office Developer Tools for Visual Studio 2013 – March 2014 Update (or higher) installed.

The Scenario

In this example, we will be tasked with producing an application that meets the following requirements for a order tracking system:

  • Products
    • Add Products
    • Edit Products
  • Orders
    • Add Orders
    • Edit Orders
      • Add Order Details
      • Edit Order Details
      • Delete Order Details
    • Delete Orders
  • Business Rules
    • Allow the current user to only see their orders
  • Features
    • Display the number of orders for a User
    • Display the number of order details for an order


The application allows you to create a list of Products.


Products can be edited.


Orders can be created.


An Order consists of multiple Order Details.


An Order Detail consists of a Product, selected from the list of available Products and a quantity.

Creating The Application


Open Visual Studio and select File, then New Project.


Create a new LightSwitch HTML Application.


The application will be created.


The application will display in the Solution Explorer.


Right-Click on the Data Sources folder in the Server project and select Add Table.


Click on the table name to edit it.

Change the table name to Product.


AAlso, add ProductName and ProductPrice fields to the table.


Click the strong>Save button to save the table.


Create an Order table (with the fields in the image above).


Create an OrderDetail table (with the fields in the image above).

Create Relationships

You will always want to make relationships when tables are related. This allows for optimal strong>LightSwitch application construction. When creating queries, having relationships defined allows you to simply type a period (“.”) and traverse from one entity to another. This saves a lot of coding work and reduces coding errors.

When creating user interfaces, defining relationships allows you to save a lot of coding work because LightSwitch will be able to automatically associate, for example, Order Details with their associated Order.


Click on the Relationship button to create a relationship between the Order Detail and the Product table.


A box will appear. Select Product for the To table and click OK (ensure the other fields match the image above).


You will see that a relationship has been created. you can double-click on the line to edit the relationship.


Click on the Relationship button again and make a relationship to the Order table.

Create a Filter

One feature we are required to implement is to only show a user their own orders (and allow an administrator to see all orders). We must keep in mind that all LightSwitch applications expose all data via OData so we must always set security in the server-side code not only in the client-side code (such as the HTML or Silverlight LightSwitch clients).


The first thing we need to do is turn on security.


Next, we open the Orders table and select Write Code,, then Orders_Filter.

Use the following code for the method:

         partial void Orders_Filter(ref Expression<Func<Order, bool>> filter)
        {
            // Only show the Orders for the current user
            filter = (x => x.UserName == this.Application.User.Name);
        }

All data that accesses this table will pass through this filter.

Set Defaults

Keeping in mind that we must set everything that relates to security in server-side code, we realize that marking orders with the UserName of the current user must be set using server-side code so that the UserName cannot be set improperly.


Open the strong Orders table and select Write Code, then Orders_Inserting. Use the following code for the method:

         partial void Orders_Inserting(Order entity)
        {
            // Set the Username
            entity.UserName = this.Application.User.Name;
        }

Do the same for the Orders_Updating event.

Later, we will also set the UserName using client-side code, however, the server side code will always run and overwrite any value set client-side.

Create a Query

Another feature we are required to implement is to show the number of orders for the current user. We will make a query that we can later consume from the client-side.


Right-click on the Orders table and select Add Query.


Name the query OrdersForUser by clicking on the title and editing it. Save it first, then select the OrdersForUser PreprocessQuery.

Use the following code for the method:

         partial void OrdersForUser_PreprocessQuery(ref IQueryable<Order> query)
        {
            // Only show the Orders for the current user
            query = query.Where(x => x.UserName == this.Application.User.Name);
        }

Create The User Interface For Products


We will first create a screen that will allow us to see Products.

Right-click on the Client node in the Solution Explorer and select Add Screen.


Create a Common Screen Set using the Products table.


The screens will be created.


Hit F5 to run the application.

Note: You will be automatically logged in as TestUser when debugging.


Click the Add button to add a Product.


Add a product and click the Save button to save it.


The Product will show in a list.

Click on the Product to display it in the view detail screen.


Click the Edit button to edit the record.

Click the web browser back button to return to the previous page.

Create The Main Page


We will now create the Main screen.

Right-click on the Screens folder and select Add Screen…


Create a new screen called Main using the Orders table for Screen Data.


The first thing we want to do is open a new screen when the user clicks on a Order in the list.

Click on the the Tile List control, and select the Item Tap action in the Properties for the control.


When the Edit ItemTap Action dialog opens, connect the screen to a new Edit screen.

Select Choose an existing method.

Select Orders.editSelected.

For Navigate To, select (New Screen…) and click OK.


The Add New Screen box will show. Select the Order Details and Order OrderDetails and click OK.


On the Main page, we need to add a button to create a new Order.

Open the Command Bar on the Main page and click the add button to create a link to the AddEditOrder page (in the Add mode).


Right-click on the Main screen and select Set as Home Screen, so that it will be the first screen that comes up when we run the application.

Looking At The Application So Far…


Run the application.


We see that we can navigate to the Products page using the dropdown.


When we click the Add Order button to open the the Add Edit Order dialog, the User Name is not filled in for us (also it should be read only).

The Order Date should also be set to the current date as its default value.


When we switch to the Order Details tab, we do not have a button to add an Order Detail.

Close the web browser and return to Visual Studio.

Create The Order Detail Edit Screen


To allow us to create and edit a Order Detail record, open the AddEditOrder screen and under Order Details (Tab), select Add under the Command Bar.

Select the addAndEditNew method of the OrderDetails collection and (New Screen) for Navigate To.


When the Add New Screen dialog shows, select OrderDetail Details as Additional Data to Include.


When the AddEditOrderDetail screen opens, right-click on the Rows Layout that contains the Order dropdown and delete it.

We don’t need to show the Order (and allow it to be changed) because it will be set by the time the user gets to this screen.


We will create a button to allow the user to edit a Order Detail.

Return to the AddEditOrder screen.

Click on the OrderDetails Tile List, and in the Properties, select the Item Tap event.

In the Edit ItemTap Action dialog, select OrderDetails.editSelected and Navigate To: Add Edit Order Detail (the screen you created in the previous step).


When we run the application, we now have a button to Add Order Detail.


We can click on the plus in a circle icon in the Product box to see a list so we can select a Product.


However, when we create a Order Detail, we see that the display can be improved.

Close the web browser and return to Visual Studio.

Formatting Order Details


We return to the Add Edit Order screen and change the Order Details Tile List control to a List.


Next, we change the Rows Layout control under the List control to a Custom Control.


In the Properties for the Custom Control we select Edit Render Code.

We use the following code:

myapp.AddEditOrder.rows_render = function (element, contentItem) {
    // We need to wait until the Products for the Order Detail are loaded
    // so we create a binding to "value.Product.ProductName"
    // When the data is loaded the binding will be raised
    // We will then have all the data required for our display
    contentItem.dataBind("value.Product.ProductName", function (newValue) {
        // clear the element
        element.innerHTML = "";
        // Create a template
        var itemTemplate = $("<div><div>");
        // Get the Product name and quantity
        var ProductName = contentItem.value.Product.ProductName;
        var ProductQuantity = "";
        if (contentItem.value.Quantity !== undefined) {
            ProductQuantity = ' [' + contentItem.value.Quantity + ']';
        }
        // Create the final display
        var FinalName = $("<h2>").text(ProductName + ProductQuantity);
        // Complete the template
        FinalName.appendTo($(itemTemplate));
        itemTemplate.appendTo($(element));
    });
};

(note: this codes uses Promises, for more information about Promises see: Using Promises In Visual Studio LightSwitch. Also see: Writing JavaScript That Implements The Binding Pattern In Visual Studio LightSwitch)


When we run the application, the output is formatted as we desire.

Setting default Values


If we run the application, and click the Add Order button…


…and try to create an Order it wont save.

We are missing the User Name. We have already added code to overwrite the User Name with the current user, but since we made it a required field, it must still be supplied. We could just make the User Name field a text box and allow the user to type it in, but we can use ServerApplicationContext to insert it client side automatically.

See the following article for a step by step tutorial: Retrieving The Current User In The LightSwitch HTML Client.

Using Server Application Context

We will now create a file handler that will use the Server Application Context API to retrieve the currently logged in user’s User Name. We will then call that handler from JavaScript code on the client-side, to fill in the value on the screen.


Right-click on the Server project and select Add then New Folder.

Create a folder named Web.


Right-click on the Web folder and select Add then New Item.


Create a new Generic Handler named GetUserName.ashx.

(note: you must create the file from scratch so that the proper references are added to the project. If you simply copy and paste, or drag and drop the file into the project, it will not work.)

Use the following code for the file:

using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;

namespace LightSwitchApplication.Web
{
    public class GetUserName : IHttpHandler
    {
        public void ProcessRequest(HttpContext context)
        {
            using (var serverContext = ServerApplicationContext.CreateContext())
            {
                context.Response.ContentType = "text/plain";
                context.Response.Write(serverContext.Application.User.Name);
            }
        }
        public bool IsReusable
        {
            get
            {
                return false;
            }
        }
    }
}


Open the Order table, select the HTML Client (tab), Write Code, and then the created method.

Use the following code for the method:

myapp.Order.created = function (entity) {
    // Set the default date for the Order
    entity.OrderDate = new Date();

    // Using a Promise object we can call the CallGetUserName function
    msls.promiseOperation(CallGetUserName).then(function PromiseSuccess(PromiseResult) {
        // Set the result of the CallGetUserName function to the
        // UserName of the entity
        entity.UserName = PromiseResult;
    });
};

// This function will be wrapped in a Promise object
function CallGetUserName(operation) {
    $.ajax({
        type: 'post',
        data: {},
        url: '../web/GetUserName.ashx',
        success: operation.code(function AjaxSuccess(AjaxResult) {
            operation.complete(AjaxResult);
        })
    });
}

(note: see Using Promises In Visual Studio LightSwitch for more information on using the msls.promiseOperation)


Lastly, we open the AddEditOrder screen and change the User Name control from a Text Box to a Text label.


When we run the application, the User Name and Date are now set when a new record is created.

You will now be able to create and save records.

Calling A Custom Query

Next, we will call the query we created earlier so that we can display the number of Orders for the current user.


Open the Main screen, select Add Data Item, and create a Integer property.


Drag and drop the property from the View Model to the screen layout.


In the Properties, make the label Left-aligned.


To set the value for the property, select Write Code, then the created method.

Use the following code:

myapp.Main.created = function (screen) {
    myapp.activeDataWorkspace.ApplicationData.OrdersForUser().execute().then(function (results) {
        var TotalCountOfOrders = CountOrders(results);
        screen.TotalOrdersForCurrentUser = TotalCountOfOrders.toString();
    });
};

function CountOrders(Orders) {
    var TotalOrders = 0;
    var orders = Orders.results;
    orders.forEach(function (order) {
        TotalOrders = TotalOrders + 1;
    });
    return TotalOrders;
}


When we run the application we see a count of the Orders.

Calling A Custom JavaScript Query


Now, we desire to show the number of associated Order Details when displaying an Order on the main page.

First, we open the Main page and delete the User Name and Created By fields in the Tile List.


Add the Id field to the list.


Change the control to a Custom Control.

Use the following code for the Render method of the control:

myapp.Main.Id_render = function (element, contentItem) {
    // Get the current OrderId
    var OrderId = contentItem.value;
    var Int32 = ':Int32';
    // Get all the OrderDetails associated with the current Order
    var filter = '(Order/Id eq ' + msls._toODataString(OrderId, Int32) + ')';
    msls.showProgress(myapp.activeDataWorkspace.ApplicationData.OrderDetails
    .filter(filter)
    .execute()
    .then(function (result) {
        // Loop through each record in the result
        var index = 0;
        var Entities = result.results;
        Entities.forEach(function (entity) {
            // Count the Order Details
            index = index + 1;
        })
        // Set the final output
        var NumberOfOrderDetails = $('<label class=msls-label-text> Number of Order Details: ' + index + '</label>');
        NumberOfOrderDetails.appendTo($(element));
    }))
};


When we run the application, we see the number of Order Detail records for the Order.

However, we now notice that the totals on the Main page do not show the correct amounts until the page is refreshed. We can automatically refresh the page…

Automatically Refreshing the Page By Using A Custom Button


We can create a custom button by selecting the Item Tap event for the Tile List on the Main Page and selecting Write my own method.


The method will show up in the View Model on the left side of the screen designer.

Right-click on it and select Edit Execute Code.

Use the following code for the method:

myapp.Main.Orders_ItemTap_execute = function (screen) {
    myapp.showAddEditOrder(null, {
        beforeShown: function (addEditOrderScreen) {
            // Set the Order on the AddEditOrder screen
            // to the selected Order on the Main screen
            addEditOrderScreen.Order = screen.Orders.selectedItem;
        },
        afterClosed: function (addEditScreen, navigationAction) {
            // If the user commits the change,
            // update the selected order on the Main screen
            if (navigationAction === msls.NavigateBackAction.commit) {
                // *****************************************
                // Refresh the Orders
                screen.Orders.load();
            }
        }
    });
};


After editing a record, the totals are automatically updated.

Deleting Records


Open the Add Edit Order Detail screen and add a button to the Command Bar.

Make a Delete method for the button.


Right-click on the Delete method in the View Model and select Edit Execute Code.

Use the following code for the method:

myapp.AddEditOrderDetail.Delete_execute = function (screen) {
    screen.OrderDetail.deleteEntity();
    return myapp.commitChanges().then(null, function fail(e) {
        myapp.cancelChanges();
        throw e;
    });
};


When editing an Order Detail the Delete button will now show.


You will have to click the Save button on the Add Edit Order page to commit the change.

We can also add a Delete button to the Add Edit Order screen using the following code:

myapp.AddEditOrder.Delete_execute = function (screen) {
    screen.Order.deleteEntity();
    myapp.commitChanges().then(null, function fail(e) {
        msls.showMessageBox(e.message, {
            title: "Error",
            buttons: msls.MessageBoxButtons.ok
        }).then(function (result) {
            if (result === msls.MessageBoxResult.ok) {
                // Discard Changes
                screen.details.dataWorkspace.ApplicationData
                    .details.discardChanges();
            }
        });
    });
};


You will notice that if we try to delete an Order that still has Order Detail records…


…it will throw an error because the relationship that we created between the tables earlier was set to not allow an Order to be deleted if there were associated records.

Delete all the Order Details first and then you can delete the Order.

LightSwitch Help Website Articles



LightSwitch Team HTML and JavaScript Articles

License

This article, along with any associated source code and files, is licensed under The Code Project Open License (CPOL)

Share

About the Author

defwebserver
Software Developer (Senior) http://ADefWebserver.com
United States United States
Michael Washington is a Microsoft MVP. He is a ASP.NET and
C# programmer.
He is the founder of
LightSwitchHelpWebsite.com

He has a son, Zachary and resides in Los Angeles with his wife Valerie.

He is the Author of:
Follow on   Twitter

Comments and Discussions


Newsthanks for this article Pin
Member 822144229-Jun-14 7:07
memberMember 822144229-Jun-14 7:07
GeneralRe: thanks for this article Pin
defwebserver29-Jun-14 8:44
memberdefwebserver29-Jun-14 8:44
NewsVery nice Pin
HamidYaseen26-Mar-14 13:01
professionalHamidYaseen26-Mar-14 13:01
GeneralRe: Very nice Pin
defwebserver26-Mar-14 13:21
memberdefwebserver26-Mar-14 13:21
GeneralMy vote of 5 Pin
Christian Amado19-Mar-14 3:17
memberChristian Amado19-Mar-14 3:17
GeneralRe: My vote of 5 Pin
defwebserver19-Mar-14 3:26
memberdefwebserver19-Mar-14 3:26

General General    News News    Suggestion Suggestion    Question Question    Bug Bug    Answer Answer    Joke Joke    Rant Rant    Admin Admin

Use Ctrl+Left/Right to switch messages, Ctrl+Up/Down to switch threads, Ctrl+Shift+Left/Right to switch pages.

| Advertise | Privacy | Terms of Use | Mobile
Web03 | 2.8.150520.1 | Last Updated 24 Aug 2014
Article Copyright 2014 by defwebserver
Everything else Copyright © CodeProject, 1999-2015
Layout: fixed | fluid
