Light Speed Inline Editing Using ASP.NET AJAX and Web Services(Architecture and Customization) - Part II

Read Part I here.

• Download source - 3.65 KB
• Download demo - 120.18 KB

In Part I of the article I showed how to use IEC (Inline Edit Controller) to enable inline editing in grid. We've used this inline editing in a real project - TargetProcess - ASP.NET based agile project management software. This part describes the architecture and advanced features like validation and extension.

Basic Classes

Inline editing solution consists of three classes:

• InlineEditController- Controller class that handles inline editing
• EditAreaSettings- Class that stores information about what should be processed in IEC
• TransactObject- Helper object that manages saving procedure (it acts as a synchronizer and restores old values in case of server side error as well as confirms correct saving)

var editAreasSettings = new Array();
var shipNameEditAreaSettings =
    new EditAreaSettings("ShipName","ShipNameIdPrefix",null, true);
editAreasSettings.push(shipNameEditAreaSettings);
var shipAddressAreaSettings = new EditAreaSettings("ShipAddress","ShipAddressIdPrefix");
editAreasSettings.push(shipAddressAreaSettings);
var shipRegionAreaSettings = new EditAreaSettings("ShipRegion","ShipRegionIdPrefix");
editAreasSettings.push(shipRegionAreaSettings);
var inlineEditController =
    new InlineEditController('gridID', editAreasSettings, onSaveEventHandler, true);

function onSaveEventHandler(retObj)
{
  var transactionObj = new TransactionObject(retObj.itemID, inlineEditController);
  transactionObj.onStatusSuccess =  onRequestComplete;
  transactionObj.onStatusError =  onRequestError;
  retObj.OrderID  = retObj.itemID;
  TargetProcess.DaoTraining.BusinessLogicLayer.OrderService.UpdateOrder(retObj,
                                     transactionObj.onSaveSuccess ,
                                     transactionObj.onSaveError)
}

Let's take a look at all the classes.

InlineEditController

Controller class that handles inline editing.

 var inlineEditControllerObj = new InlineEditController
                        (gridID, editAreasSettings , onSaveEventHandler, isExplicitSave)

Arguments

• gridID
  Id of the grid

• editAreasSettings
  Array of EditAreaSettings objects

• isExplicitSave
  Flag specifying whether a row in edit state should be saved when another row is set into edit state. For example, when user clicks on another row, the first row will be saved if this flag is set to true.

• OnSaveEventHandler
  Callback function that is called on save event

• IEC does not know how to save the item, so the saving procedure should be provided (for example, it may be Web Service call).

  function onSaveEventHandler(retObj){
       retObj.OrderID  = retObj.itemID;
       MyWebService.OrderService.UpdateItem(retOb);
  }

• retObj
  Object that contains edited values

Public Methods

• inlineEditControllerObj.commitChanges(itemID)
  This method should be called to confirm that data was successfully saved and there is no need to restore initial values.

• inlineEditControllerObj.abandonChanges(itemID)
  This method should be called to restore the initial values in case of server side error.

EditAreaSettings

Class that stores information about what should be processed in IEC. The IEC should have information about what and how it should be updated. The EditAreaSettings object holds all essential information to edit the item.

 var editAreaSettingsObj  = new EditAreaSettings(areaName,
                        areaPrefix,
                        areaDataSourceControlID,
                        isFocus,
                        onSelectValue,
                        onExtractEditedValue,
                        onRenderEditedValue,
                        onCancelEditValue,
                        onEditValue)

Arguments

• areaName
  Maps the edited values into retObj (as you remember retObj is passed into OnSaveEventHandler and stores all new values that should be saved).

• areaPrefix
  We find the "Edit Area" using this argument. The full id of "Edit Area" is areaPrefix+"id of item".

   <asp:TemplateField HeaderText="Ship Name">
             <ItemTemplate>

                   <span id="ShipNameIdPrefix<%# Eval("OrderID")%>">
                      <asp:Label ID="Label1" runat="server"
                           Text='<%#Eval("ShipName")%>'></asp:Label>
                   </span>
             </ItemTemplate>
   </asp:TemplateField>

       var shipNameEditAreaSettings =
           new EditAreaSettings("ShipName","ShipNameIdPrefix",null, true);
       editAreasSettings.push(shipNameEditAreaSettings);
       var inlineEditController =
          new InlineEditController('uxGridID', editAreasSettings,
              onSaveEventHandler, true);
  ...

• areaDataSourceControlID
  Id of a dataSource control

  When edit state is enabled for row, all labels are transferred into editable state. It means that text will be replaced by input field. Another scenario is when text value should be replaced by Select Box with predefined values to select. IEC will try to set the value in the Select box based on text in column. DataSourceControl is a drop down that contains all required values.

• isFocus
  Should "Edit Area" receive a focus when edit state becomes active?

• onSelectValue
  In most cases, you will use this handler to set the correct value in DataSource Control.

• onExtractEditedValue
  A custom handler may be used to extract edited values from "Edit Areas".

• onCancelEditValue
  A custom handler may be used to set edit area into original (read-only) state.

• onEditValue
  A custom handler may be used to set edit area into cool (inline edit) state.

• OnRenderEditedValue
  A custom handler may be used to render original (read-only) with some specialties, like display an image that represents Priority or something like that.

All these handlers can be omitted. You should use them for complex cases.

TransactObject

Helper object that manages saving procedure (it acts as a synchronizer and restores old values in case of server side error as well as confirms valid saving).

var transactionObject  =  new TransactionObject(itemID, inlineEditController);

Arguments

• itemID
  ID of an item that will be updated.
• inlineEditController
  The reference to the IEC.

IEC LifeCycle

IEC life-cycle is not a simple thing I should say. It is quite hard to describe how it works in short, but let's try.

Stage 1. IEC Initialization

IEC binds event handlers to corresponding elements through the whole grid. We have just three handlers: Edit, Save and Cancel. So bind them to required controls.

function InlineEditController
    (gridID, editAreasSettings, onSaveEventHandler, isExplicitSave)
 {
   ...
   //******************** Fields ****************************
   var activeInlineEditPanel;
   var thisRefInlineEditController = this;
   //the object that stores the previous values of item,
   //used in case of calling abandonChanges(itemId)
   var previousStates  = new Object();
   attachEvents();
   function attachEvents()
   {
       var grid = document.getElementById(gridID);
       if(grid == null)
       {
           alert("error: Unable to find a grid.");
           return;
       }
       //assign the click handler to the grid(HTMLTable)
       grid.onclick = onGridClick;

       for(var index=0; index < grid.rows.length;index++)
       {
         var cells = grid.rows[index].cells;
         for(var index1=0; index1 < cells.length; index1++)
         {
              var element = findInlineEditPanelInElement(cells[index1]);
              if(element == null)
                 continue;
              if(element.attributes == null)
                 continue;
              //look up for "Inline Edit Panel"
              if(element.attributes[INLINE_PANEL_FLAG_ATTRIBUTE] != null)
              {
                 var row = findRowForElement(element);
                 row.ondblclick = onDblClickRow;
                 row.onkeypress = onEditing;
                 var children =  extractDHTMLElements(element);
                 for(var index2 = 0; index2 < children.length; index2++)
                 {
                      //look up for save, edit and cancel image buttons
                      var control = children[index2];
                      switch(control.attributes[INLINE_ACTION_ATTRIBUTE].nodeValue)
                      {
                         case INLINE_EDIT_ACTION:
                           control.onclick = onEditAction;
                         break;
                         case INLINE_SAVE_ACTION:
                           control.onclick = onSaveAction;
            ...

Stage 2. Enabling Edit Mode

What happens when the user clicks Edit link? Maybe the system crashes as usual? Not at this time! It sets the table row into editable state. The most interesting method is editRow (hmm, it looks like it should be refactored a little, ok, I will leave you some space for improvements :). So what does it do?

1. Hides some actions and shows inline editing actions instead.
2. Highlights editable row with fancy green color (well, may be customized if you prefer pink).
3. Stores current values (we may need them later if user pushes Cancel or some server problems arises).
4. Calls specific onEditValuehandler if exists.
5. Creates input element to allow user to actually edit something.

//********************* Events ************************
    ......
   //fires on edit image click
   function onEditAction()
   {   //suppose that some row can be in Edit State
       cancelEditRow();
       editRow(this.parentNode);
   }

   //fires on double click on row
   function onDblClickRow(eventObj)
   {
      if(eventObj == null)
         eventObj = event;
      var srcElement = eventObj.srcElement ? eventObj.srcElement : eventObj.target;
      if(srcElement.tagName == "A" )
        return;
      //look up for "inline edit panel"
      var inlineEditPanel = findInlineEditPanelInElement(this);
      if(inlineEditPanel)
      {
         cancelEditRow();
         editRow(inlineEditPanel);
      }
   }

   function editRow(inlineEditPanel)
   {
       if(activeInlineEditPanel != null)
       {
            alert("error: Unable to set edit state.
                  There must be no item in edit state.");
            return;
       }

       activeInlineEditPanel = inlineEditPanel;
       var children = extractDHTMLElements(activeInlineEditPanel);
       for(var index=0; index < children.length; index++)
       {
          var control = children[index];
          switch(control.attributes[INLINE_ACTION_ATTRIBUTE].nodeValue)
          {
             case INLINE_EDIT_ACTION: control.style.display='none'; break;
             case INLINE_SAVE_ACTION: control.style.display='';break;
             case INLINE_CANCEL_ACTION: control.style.display='';break;
             default:/* "Do nothing" */;
          }
       }

       highLightInlineEditRow(INLINE_ROW_BACKGROUNDCOLOR_ACTIVE);
       var itemID = getActiveInlineEditPanelID();
       if(itemID == null)
       {
           alert("error: Unable to find item id.");
           return;
       }
       // create a new object to store previuos values (just in the case)
       previousStates[itemID] = new Object();
       for(var index=0; index < editAreasSettings.length; index++)
       {
          var editAreaSettings = editAreasSettings[index];

         //get the Edit Area ID
          var editAreaID = editAreaSettings.areaPrefix+itemID
          var editArea = document.getElementById(editAreaID);
          if(editArea == null)
             continue;

          //saving particular value
          previousStates[itemID][editAreaID] = editArea.parentNode.innerHTML;
          //check if there is specific handler on edit event.
          if(editAreaSettings.onEditValue != null)
          {
               editAreaSettings.onEditValue(editAreaSettings, editArea);
          }
          //otherwise call predefined handler of IEC
          else
          {
             if(editAreaSettings.areaDataSourceControlID == null)
                 editTextField(editArea);
             else
                 editDataSourceField(editArea, editAreaSettings.areaDataSourceControlID);
          }
          //check if there is specific handler on select event.
          if(editAreaSettings.onSelectValue != null)
             editAreaSettings.onSelectValue(editAreaSettings, editArea);
          else
             //otherwise call predefined handler of IEC
             selectValueInDataSourceControl(editArea);

           if(editAreaSettings.isFocus)
             setFocusForEditableField(editArea);
       }
   }

There are two possible customizations at this stage:

• onEditValue
  A custom handler may be used to set edit area into cool (inline edit) state. Example

• onSelectValue
  A custom handler may be used to set correct value in DataSourceControl. Example

Stage 3. Save Changes

First we should extract new values from form fields. The methods with very original names extractEditedValues and extractEditedValue do the entire job. As a result we have an object with all new values. Then we call onSaveEventHandler to save new values into the database.

function onSaveAction()
   {
       var obj = extractEditedValues();
       //call the saving handler(the procedure that is defined outside of IEC)
       if(onSaveEventHandler != null)
       onSaveEventHandler(obj);
       //get row back into read state
       cancelEditRow();
   }

   function extractEditedValues()
   {
       if(activeInlineEditPanel == null)
          return null;
       var retObj = new Object();
       var itemID = getActiveInlineEditPanelID();
       if(itemID == null)
       {
           alert("error: Unable to find item id.");
           return;
       }
       retObj.itemID = itemID;
       for(var index=0; index < editAreasSettings.length; index++)
       {
            var editAreaSettings = editAreasSettings[index];
            var editArea = document.getElementById(editAreaSettings.areaPrefix+itemID);
            if(editArea == null)
               continue;
            //check if there is specific handler on extract data event.
            if(editAreaSettings.onExtractEditedValue != null)
                editAreaSettings.onExtractEditedValue
                (retObj, editAreaSettings, editArea);
            else
                //otherwise call predefined event of IEC
                extractEditedValue(retObj, editAreaSettings, editArea);
       }
       //return the obj that holds new edited values
       return retObj;
   }

  function extractEditedValue(refRetObj, editAreaSettings, editArea)
   {
          var children = extractDHTMLElements(editArea);
          if(editAreaSettings.areaDataSourceControlID == null)
          {  //save new value
             refRetObj[editAreaSettings.areaName] = children[1].value;
             //assign new value for readable field
             children[0].innerHTML = children[1].value;
          }
          else if(children[1].tagName == 'SELECT' )
          {
             var select = children[1];
             refRetObj[editAreaSettings.areaName] =
                   (trimText(select.options[select.selectedIndex].value)=="")
                   ? null : select.options[select.selectedIndex].value;
             children[0].innerHTML =
                   (trimText(select.options[select.selectedIndex].value)=="") ?
                    "" : select.options[select.selectedIndex].text;
         }
   }

There is one possible customization at this stage.

onExtractEditedValue
A custom handler may be used to extract edited values from "Edit Areas". Example

Stage 4. Disabling Edit Mode

When we saved changes, the table row should be turned back into original state. Not such a trivial thing in fact. The cancelEditRow function is responsible for the transition.

function onEditing(eventObj)
   {
      if(eventObj == null)
         eventObj = event;
      //27 - key code of escape key
      if(eventObj.keyCode == 27)
        onCancelAction();
      ...

  }
   function onCancelAction()
   {
       cancelEditRow();
   }

 function cancelEditRow()
   {
       if(activeInlineEditPanel == null)
          return;

       var children = extractDHTMLElements(activeInlineEditPanel);
       for(var index=0; index < children.length; index++)
       {
          var control = children[index];
          switch(control.attributes[INLINE_ACTION_ATTRIBUTE].nodeValue)
          {
             case INLINE_EDIT_ACTION: control.style.display=''; break;
             case INLINE_SAVE_ACTION: control.style.display='none';break;
             case INLINE_CANCEL_ACTION: control.style.display='none';break;
             default:/* "Do nothing" */;
          }
       }

       highLightInlineEditRow(INLINE_ROW_BACKGROUNDCOLOR_NORMAL);
       var itemID = getActiveInlineEditPanelID();
       if(itemID == null)
       {
           alert("error: Unable to find item id.");
           activeInlineEditPanel = null;
           return;
       }
       for(var index=0; index < editAreasSettings.length; index++)
       {
          var editAreaSettings = editAreasSettings[index];
          var editArea = document.getElementById(editAreaSettings.areaPrefix+itemID);
          if(editArea == null)
             continue;

          if(editAreaSettings.onCancelEditValue != null)
          {
               editAreaSettings.onCancelEditValue(editAreaSettings, editArea);
          }
          else
            {
              if(editAreaSettings.areaDataSourceControlID == null)
                cancelEditTextField(editArea);
              else
                cancelEditDataSourceField(editArea);
            }

          if(editAreaSettings.onRenderEditedValue!=null)
              editAreaSettings.onRenderEditedValue(editAreaSettings, editArea);
       }
       activeInlineEditPanel = null;
   }

There are two possible customizations at this stage.

onCancelEditedValue
A custom handler may be used to set edit area into original (read-only) state. Example

onRenderEditedValue
A custom handler may be used to render original (read-only) label with some specialties, like display an image that represents Priority or something like that. Example

TransactObject Implementation

TransactObject is a helper object that manages saving procedure (it acts as a synchronizer and restores old values in case of server side error as well as confirms valid saving).

The IEC replaces editable fields by text with new values, while the server is still processing the request. Since updating is asynchronous, we have a problem of Web service exception synchronization. What happens when an object can't be saved and we receive an exception? New values will be set for the row, but these values are not correct anymore.

Another problem is that AJAX.NET wraps all exceptions from Web service into WebServerError class and it's impossible to get information about what item was failed. TransactionObject handles these problems. It has a reference to IEC and can restore the initial values in case of error. IEC holds the initial values of the item till the commitChanges or abandonChanges method call.

function onSaveEventHandler(retObj)
{
   var transactionObj = new TransactionObject(retObj.itemID, inlineEditController);
   transactionObj.onStatusSuccess = onRequestComplete;
   transactionObj.onStatusError = onRequestError;
   retObj.OrderID  = retObj.itemID;
   TargetProcess.DaoTraining.BusinessLogicLayer.OrderService.UpdateOrder(retObj,
                                     transactionObj.onSaveSuccess ,
                                     transactionObj.onSaveError)
}

function TransactionObject(itemID, inlineEditController, onSuccessStatus, onErrorStatus)
{
  var thisRefTransactionObject = this;
  this.inlineEditController = inlineEditController;
  this.itemID = itemID;
  this.onStatusSuccess = onSuccessStatus;
  this.onStatusError = onErrorStatus;

  //--- Events ---
  this.onSaveSuccess = function(result)
  {
    //remove the initial values for item from IEC.
    thisRefTransactionObject.inlineEditController.commitChanges
          (thisRefTransactionObject.itemID);
    //call custom handler if such handler is provided
    if(thisRefTransactionObject.onStatusSuccess)
        thisRefTransactionObject.onStatusSuccess(result);

  }

  this.onSaveError = function(ex, context)
  {
     //restore the initial values for item
     thisRefTransactionObject.inlineEditController.abandonChanges
          (thisRefTransactionObject.itemID);
     if(thisRefTransactionObject.onStatusError)
        thisRefTransactionObject.onStatusError(ex);

  }

Extending Base Functionality. Custom Edit Handler

By default IEC has a simple logic for text and drop down editing, since it is impossible to implement all cases.

Sometimes, you get into a situation when the base functionality is not enough. For instance, Priority property of Order class. When the row is in read-only state it must show the priority image and in edit state it must show the select box.

   <asp:TemplateField>
          <ItemTemplate>
            <%--priorityname attribute holds priority value --%>
                <span priorityname='<%#Eval("Priority")%>'
                     id="PriorityIdPrefix<%# Eval("OrderID")%>">
                      <span>
                            <%#GetPriorityHTML(Container.DataItem)%>
                      </span>
                </span>
          </ItemTemplate>
   </asp:TemplateField>

var prioritySettings = new EditAreaSettings
                ("Priority","PriorityIdPrefix","uxPriorities");
prioritySettings.onRenderEditedValue = onRenderPriorityValue;
prioritySettings.onSelectValue = onSelectPriorityValue;
editAreasSettings.push(prioritySettings);
var inlineEditController = new InlineEditController
           ('<%=uxOrders.ClientID%>', editAreasSettings, onSaveEventHandler, true);
var  HIGHEST_PRIORITY_IMAGE =  "<%=HIGHEST_PRIORITY_IMAGE%>";
var  NORMAL_PRIORITY_IMAGE  =  "<%=NORMAL_PRIORITY_IMAGE %>";
var  LOWEST_PRIORITY_IMAGE  =  "<%=LOWEST_PRIORITY_IMAGE %>";
var  HIGHEST_PRIORITY = "<%=Priority.Highest %>";
var  NORMAL_PRIORITY  = "<%=Priority.Normal %>";
var  LOWEST_PRIORITY  = "<%=Priority.Lowest%>";
var  PRIORITY_ATTR  = "priorityname";

It is required to provide two handlers: onRenderPriorityValue and onSelectPriorityValue.

onSelectPriorityValue handler just selects the predefined value in Select box.

function onSelectPriorityValue(editAreaSettings, editArea)
{
   var dataSourceControl =
        document.getElementById(editAreaSettings.areaDataSourceControlID);
   dataSourceControl.value =  editArea.attributes[PRIORITY_ATTR].nodeValue;
}

onRenderPriorityValue converts Priority value into a specific image.

function onRenderPriorityValue(editAreaSettings, editArea)
{
    var dataSourceControl =
        document.getElementById(editAreaSettings.areaDataSourceControlID);
    var children = extractDHTMLElements(editArea);
    var readField = children[0];
    switch(dataSourceControl.value)
    {
        case HIGHEST_PRIORITY:
            readField.innerHTML = HIGHEST_PRIORITY_IMAGE;
        break;
        case NORMAL_PRIORITY:
           readField.innerHTML =  NORMAL_PRIORITY_IMAGE;
        break;
        case LOWEST_PRIORITY:
           readField.innerHTML =  LOWEST_PRIORITY_IMAGE;
        default:/*Do nothing*/
    }
    editArea.attributes[PRIORITY_ATTR].nodeValue = dataSourceControl.value;
}

This situation is quite a unique case. In most case the base logic of IEC will fit your requirements. For instance, Country property of Order class works just fine.

 <asp:TemplateField HeaderText="Ship Country">
  <ItemTemplate>
   <span id="ShipCountryIdPrefix<%# Eval("OrderID")%>">
    <asp:Label ID="Label1" runat="server" Text='<%#Eval("ShipCountry")%>'></asp:Label>
   </span>
  </ItemTemplate>
 </asp:TemplateField>

 .....

  <select style="display: none" id="uxCountries">
  <option>-- Select Country</option>
  <option value="USA">United States</option>
  <option value="Canada">Canada</option>
  <option value="Mexico">Mexico</option>
  <option value="Afghanistan">Afghanistan</option>
  <option value="Albania">Albania</option>
 ....

var shipCountrySettings  =
    new EditAreaSettings("ShipCountry","ShipCountryIdPrefix","uxCountries");
editAreasSettings.push(shipCountrySettings);

As you see, there are no custom handlers. All what you need to do is to pass uxCountries ID into shipCountrySettings. The IEC will successfully select the value in Select box using the text in column and render the new value.

Extending Base Functionality. CheckBox Handler

What if you have a boolean value that is represented as a checkbox in the grid? Let's see how that can be implemented.

 <asp:TemplateField HeaderText="Rush Order">
  <ItemTemplate>
       <span id="IsRushOrderIdPrefix<%#Eval("OrderID")%>" >
          <asp:CheckBox  Enabled="false" runat="server"
              Checked='<%#Eval("isRushOrder") %>' ID="uxRushOrder" />
       </span>
  </ItemTemplate>
 </asp:TemplateField>

var isRushOrderSettings = new EditAreaSettings("IsRushOrder","IsRushOrderIdPrefix");
 isRushOrderSettings.onEditValue = onEditRushValueHandler;
isRushOrderSettings.onExtractEditedValue = onExtractRushValueHandler;
isRushOrderSettings.onCancelEditValue = onCancelEditRushValueHandler;
editAreasSettings.push(isRushOrderSettings);

I should create three custom handlers: onEditRushValueHandler, onExtractRushValueHandler, and onCancelEditRushValueHandler. onEditValue just enables checkbox.

function onEditRushValueHandler(editAreaSettings, editArea)
{
    var isRushOrderSpan = getFirstDHTMLElement(editArea);
    isRushOrderSpan.disabled = false;
    var isRushOrderChk = getFirstDHTMLElement(isRushOrderSpan);
    isRushOrderChk.disabled = false;
}

onExtractRushValueHandler gets the new value from checkbox and saves it in retObj (that is passed into onSaveEventHandler as you remember).

function onExtractRushValueHandler(retObj, editAreaSettings, editArea)
{
    var isRushOrderChk = getFirstDHTMLElement(getFirstDHTMLElement(editArea));
    retObj[editAreaSettings.areaName] = isRushOrderChk.checked;
}

onCancelEditValue disables checkbox.

function onCancelEditRushValueHandler(editAreaSettings, editArea)
{
    var isRushOrderSpan = getFirstDHTMLElement(editArea);
    isRushOrderSpan.disabled = true;
    var isRushOrderChk = getFirstDHTMLElement(isRushOrderSpan);
    isRushOrderChk.disabled = true;
}

Thus you can create custom handlers for any case, even extremely complex ones.

Input Validation

There are no standard solutions to validate input in JavaScript (like ASP.NET validators, for example), but you can still use handlers that would act as validators. Fortunately, TransactObject restores the initial values in case of server side error that can be caused by invalid input, but it's not enough. We should implement extra validation for the Freight property that is supposed to be Decimal to validate input.

   <asp:TemplateField HeaderText="Freight">
  <ItemTemplate>
   <span id="FreightIdPrefix<%# Eval("OrderID")%>">
        <asp:Label ID="Label1" runat="server" Text='<%#Eval("Freight")%>'></asp:Label>
   </span>
  </ItemTemplate>
 </asp:TemplateField>

 var freightSettings = new EditAreaSettings("Freight","FreightIdPrefix");
  freightSettings.onSelectValue = onSelectFreightValueHandler;
  editAreasSettings.push(freightSettings);

We need to implement just one handler onSelectFreightValueHandler. This handler assigns validation handler for Freight input box and it is impossible to type anything except numbers and decimal separator.

  function onSelectFreightValueHandler(editAreaSettings, editArea)
  {
   var children = extractDHTMLElements(editArea);
    //children[0] - readable field that gets invisible since the row is in editable state
    //children[1] - input field that gets added since the row is in editable state
 children[1].onkeypress = onKeyPressDecimalValueHandler;
  }

  function onKeyPressDecimalValueHandler(eventObj,obj)
  {
    var thisRef;
    if(obj == null)
      thisRef = this;
    else
      thisRef = obj;

    function isValidInput(key,value)
    {
        if(key == "." && value.indexOf(".")==-1)
          return true;
        if(isNaN(key))
           return false;
        else
           return true;
    }

    if(typeof event == "undefined")
    {
        var key =  String.fromCharCode(eventObj.charCode);
        if(eventObj.charCode == 0)
           return;
        if(!isValidInput(key, thisRef.value))
           eventObj.preventDefault();
    }
    else
    {
        var key =  String.fromCharCode(event.keyCode);
        if(!isValidInput(key, thisRef.value))
           event.returnValue = false;
    }
}

The other solution is to use TransactObject as a validator. For instance, if I try to enter invalid date TransactObject restores the initial value and shows the error message.

Now you can use inline editing in all your lists without problems.

You must Sign In to use this message board.

FAQ  Noise Tolerance Very HighHighMediumLowVery Low  Search Messages    Layout Expand All MessagesThread ViewNo Javascript (slow)No Javascript Preview    Per page 102550

Msgs 1 to 4 of 4 (Total in Forum: 4) (Refresh) FirstPrevNext

Wow Marc Leger 10:24 13 Mar '08   There ya go. Great work and contribution. Keep up the great work! Cheers, M Sign In·View Thread·PermaLink Message Automatically Removed Member 4738628 0:28 10 Jan '08   Message Automatically Removed [Message Deleted] Member 4738628 0:30 10 Jan '08   Sign In·View Thread·PermaLink 1.11/5 (3 votes) Message Automatically Removed Member 4738628 0:31 10 Jan '08   Message Automatically Removed

Last Visit: Tuesday, December 2, 2008 3:49 AM     Last Update:Tuesday, December 2, 2008 3:49 AM
