FlashMovie WebControl

• Download source - 25.7 Kb

Introduction

For those out there who have added Macromedia Flash movies to your dynamic web pages, you no doubt found it frustrating to make the movie itself dynamic. That is, dynamic variables and properties; or even the movie itself dynamic like a rotator. And even more frustrating what if you wanted default html in place just in case the Flash plug-in is not installed or you are going the route of enforcing that a certain version is installed through JavaScript, and in fact JavaScript has been disabled. Well, although this custom ASP.NET control does not sing and dance, it does make these tasks extremely easy to manage.

The FlashMovieControl wraps up all properties that can be pushed into a Flash movie, (i.e. scale, width, height, window mode... the list goes on). And does it all with great designer support, which proved to be a valuable learning experience for me. The current version of this control is currently up-to-date with the latest properties and output rendering of Macromedia 2004 Flash MX. You will find that the rendered content that is sent to the browser is exact to what is published directly from the Macromedia MX studio.

Features

• Dynamically send variables to your Flash movie:

  public class FlashMovieTest {
      protected Osmosis.Web.UI.Controls.FlashMovie FlashMovie1;

      private void function AddMovieVariables() {
          this.FlashMovie1 = new Osmosis.Web.UI.Controls.FlashMovie();
          this.FlashMovie1.MovieVariables.Add("MyVar1","MyValue1");
          this.FlashMovie1.MovieVariables.Add("MyVar2","MyValue2");
      }
  }

  -------------------------------------
  Renders as:
  <object classid= .... >
  <PARAM NAME=movie VALUE="MyMovie.swf?MyVar1=MyValue1&MyVar2=MyValue2"> ....

• Easily add HTML content just in case the Flash plug-in is unavailable on the client. (Only available with ClientScriptVersionDection). When the control is rendered, all necessary JavaScript code is rendered for version detection including the HTML content to render just in case no plug-in is available. Notice that the HTML code is wrapped up for you in the necessary document.write('') statements automatically. A huuuuuuuuuuuge time saver.

  public class FlashMovieTest {
      protected Osmosis.Web.UI.Controls.FlashMovie FlashMovie1;

      private void function AddNoFlashPluginContent() {
          this.FlashMovie1 = new Osmosis.Web.UI.Controls.FlashMovie();
          this.FlashMovie1.FlashOutputType =
              Osmosis.Web.UI.FlashOutputType.ClientScriptVersionDection;
          this.FlashMovie1.NoFlashContainer.Controls.Add(new Table());

      }
  }

  -------------------------------------
  Renders as:
  if ( MM_FlashCanPlay ) { ...

  } else{
  document.write('<table border="0" ID="Table1">');
  document.write('');
  document.write('</table>');
  }

• Almost identical to adding content to the NoFlashContainer, you can also add HTML just in case JavaScript is disabled and you are using ClientScriptVersionDection. When the control is rendered, all necessary JavaScript code is rendered for version detection. But what if the user's browser doesn't support JavaScript, you can add web controls programmatically that will render themselves within a <noscript></noscript> HTML block.

  public class FlashMovieTest {
      protected Osmosis.Web.UI.Controls.FlashMovie FlashMovie1;

      private void function AddNoFlashPluginContent() {
          this.FlashMovie1 = new Osmosis.Web.UI.Controls.FlashMovie();
          this.FlashMovie1.FlashOutputType =
            Osmosis.Web.UI.FlashOutputType.ClientScriptVersionDection;
          this.FlashMovie1.NoScriptContainer.Controls.Add(new Table());

      }
  }

  -------------------------------------
  Renders as:
  <NOSCRIPT>
      <table border="0" ID="Table1"></table>
  </NOSCRIPT>

• FS_Command support is available now. Simply specify the URI of the script tag to include in your webpage. This will render out a script tag with the SRC attribute set to your URI.

  public class FlashMovieTest {
      protected Osmosis.Web.UI.Controls.FlashMovie FlashMovie1;

      private void Page_Load(object sender, System.EventArgs e) {

          this.FlashMovie1 = new Osmosis.Web.UI.Controls.FlashMovie();
          this.FlashMovie1.FSCommandScriptUrl = "../MyJavaScriptFile.js";

      }
  }

  -------------------------------------
  Renders as:
  <script language="javascript" src="../MyJavaScriptFile.js"></script>

What are the FlashOutputType's for? (Osmosis.Web.UI.FlashOutputType)

• ClientScriptVersionDection: Tells the FlashMovieControl to render the necessary JavaScript code to perform plug-in version detection on the version that you specify. Also rendered in this mode is any NoScript/NoPlugin content that you assigned to the NoScriptContainer and NoFlashContainers.
• FlashOnly: Tells the FlashMovieControl to only render the necessary HTML to embed your movie into the webpage. Basically, everything but the client script for detecting the plug-in version.
• SWFVersionDetection: This one's a bit odd. It is the latest output type used in Macromedia's Flash Studio 2004. It uses an swf movie to detect if Flash is installed. What, it uses a Flash Movie to detect if Flash is installed on the client? It didn't make sense to me either. But in Flash MX 2004, when you publish with this flag set, it will generate an swf movie (version 4 only) that will direct you to your intended movie. Use this output method with the FlashMovieControl properties: SWF_

  ///Example of using SWFVersionDetection

  this.FlashMovie1.FlashOutputType =
     Osmosis.Web.UI.FlashOutputType.SWFVersionDetection;
  this.FlashMovie1.MovieName = "MyMacromediaGeneratedDetectionMovie.swf";

  this.FlashMovie1.SWF_DetectionAltUrl = "IfNotDetectedUrl.aspx";
  this.FlashMovie1.SWF_DetectionContentUrl = "IfDetectedUrl.aspx";

• All other output types are not supported but default to FlashOnly. I added them into the enumeration for remembrance to add in future.

Get me started using the FlashMovieControl

Make sure to reference the .dll in your project. In the Solution Explorer, locate your project and right click on the References node. Select Add Reference. Browse for the .dll file downloaded from CodeProject and click OK. To use with the designer: when your webform is in design view, open up the Toolbox and right click. Select Add/Remove Items. Browse for the .dll file downloaded from CodeProject and click OK. Now the FlashMovieControl is added to your Toolbox. Just drag it onto your page and open up your Properties window. One thing to keep in mind is to always set the MovieName property. This is the URL of the actual .swf file. If you forget to add the actual movie, your browser will hang because it is trying to locate the file that is non-existent. In a future release, I will set the control to throw an exception if no movie has been set. Below is an example of using the FlashMovieControl with ClientScriptVersionDetection as the FlashOutputType.

using System;
using System.Collections;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Web;
using System.Web.SessionState;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Web.UI.HtmlControls;

namespace FlashTest
{

    public class FlashMovieControlTest : System.Web.UI.Page
    {
        protected Osmosis.Web.UI.Controls.FlashMovie FlashMovie1;

        private void Page_Load(object sender, System.EventArgs e)
        {
            this.FlashMovie1 = new Osmosis.Web.UI.Controls.FlashMovie();

            ///Set the output type and Movie

            this.FlashMovie1.FlashOutputType =
              Osmosis.Web.UI.FlashOutputType.ClientScriptVersionDection;
            ///Always make sure you have a valid movie

            ///or your browser will hang.

            this.FlashMovie1.MovieName = "MyMovie.swf";

            /// Set the plugin version to check for

            this.FlashMovie1.MajorPluginVersion = 7;
            this.FlashMovie1.MajorPluginVersionRevision = 0;
            this.FlashMovie1.MinorPluginVersion = 0;
            this.FlashMovie1.MinorPluginVersionRevision = 0;

            ///Set some other properties

            this.FlashMovie1.MovieHeight = "400px";
            this.FlashMovie1.MovieWidth = "200px";
            this.FlashMovie1.AutoLoop = false;
            this.FlashMovie1.AutoPlay = true;
            this.FlashMovie1.FlashHorizontalAlignment =
                 Osmosis.Web.UI.FlashHorizontalAlignment.Center;
            this.FlashMovie1.FlashVerticalAlignment =
                 Osmosis.Web.UI.FlashVerticalAlignment.Top;
            this.FlashMovie1.HtmlAlignment =
                 Osmosis.Web.UI.FlashHtmlAlignment.Right;
            this.FlashMovie1.UseDeviceFonts = false;
            this.FlashMovie1.WindowMode =
                 Osmosis.Web.UI.FlashMovieWindowMode.Transparent;
            this.FlashMovie1.ShowMenu = false;
            this.FlashMovie1.MovieQuality =
                 Osmosis.Web.UI.FlashMovieQuality.AutoHigh;
            this.FlashMovie1.MovieScale =
                 Osmosis.Web.UI.FlashMovieScale.NoScale;

            /// Add some variables

            this.FlashMovie1.MovieVariables.Add("MyVar1","MyValue1");
            this.FlashMovie1.MovieVariables.Add("MyVar2","MyValue2");
            this.FlashMovie1.MovieVariables.Add("MyVar3","MyValue3");

            ///Set the NoScript and NoFlash content.

            ///In most situations where

            ///html will be displayed the content is the same for both

            this.FlashMovie1.NoFlashContainer.Controls.Add(
              this.GetDefaultHtmlContent());
            this.FlashMovie1.NoScriptContainer.Controls.Add(
              this.GetDefaultHtmlContent());
        }



        private HtmlTable GetDefaultHtmlContent(){

            HtmlTable tbl = new HtmlTable();
            HtmlTableRow tr = new HtmlTableRow();
            HtmlTableCell td = new HtmlTableCell();
            Label lbl = new Label();
            lbl.Text = "This is my default content";

            td.Controls.Add(lbl);
            tr.Cells.Add(td);
            tbl.Rows.Add(tr);
            return tbl;
        }

        #region Web Form Designer generated code
        override protected void OnInit(EventArgs e)
        {
            //

            // CODEGEN: This call is required by the ASP.NET

            // Web Form Designer.

            //

            InitializeComponent();
            base.OnInit(e);
        }

        /// <summary>

        /// Required method for Designer support - do not modify

        /// the contents of this method with the code editor.

        /// </summary>

        private void InitializeComponent()
        {
            this.Load += new System.EventHandler(this.Page_Load);

        }
        #endregion
    }
}

-------------------------------------------------------------------
Renders As......
-------------------------------------------------------------------
<SCRIPT LANGUAGE="JavaScript1.1">
<!--
var MM_contentVersion = 7;
var plugin = (navigator.mimeTypes && navigator.mimeTypes[
  "application/x-shockwave-flash"]) ?
navigator.mimeTypes["application/x-shockwave-flash"].enabledPlugin : 0;
if ( plugin ) {
var words = navigator.plugins["Shockwave Flash"].description.split(" ");
for (var i = 0; i < words.length; ++i)
{
if (isNaN(parseInt(words[i])))
continue;
var MM_PluginVersion = words[i];
}
var MM_FlashCanPlay = MM_PluginVersion >= MM_contentVersion;
}
else if (navigator.userAgent && navigator.userAgent.indexOf("MSIE")>=0
&& (navigator.appVersion.indexOf("Win") != -1)) {
document.write('<SCR' + 'IPT LANGUAGE="VBScript\"> \n');
document.write('on error resume next \n');
document.write('MM_FlashCanPlay = (
  IsObject(CreateObject("ShockwaveFlash.ShockwaveFlash." &
  MM_contentVersion)))\n');
document.write('</SCR' + 'IPT\> \n');
}
if ( MM_FlashCanPlay ) {
document.write('<OBJECT classid=
  "clsid:d27cdb6e-ae6d-11cf-96b8-444553540000"');
document.write('  codebase=
  "http://fpdownload.macromedia.com/pub/shockwave/cabs/
  flash/swflash.cab#version=7,0,0,0" ');
document.write(' ID="FlashMovie1" WIDTH="200px"
  HEIGHT="400px" ALIGN="right">');
document.write(' <PARAM NAME=movie
  VALUE="MyMovie.swf?MyVar1=MyValue1&MyVar2=MyValue2&MyVar3=MyValue3">
  <PARAM NAME=loop VALUE=false /> <PARAM NAME=menu VALUE=false />
  <PARAM NAME=scale VALUE=noscale /> <PARAM NAME=wmode VALUE=transparent />
  <PARAM NAME=salign VALUE=T /> <PARAM NAME=quality VALUE=AutoHigh/>
  <PARAM NAME=bgcolor VALUE=#ffffff/> <PARAM NAME="allowScriptAccess"
  value="SameDomain" />  ');
document.write(' <EMBED
  src="MyMovie.swf?MyVar1=MyValue1&MyVar2=MyValue2&MyVar3=MyValue3"
  loop="false" menu="false" scale="noscale" wmode="transparent"
  salign="T" quality="autohigh" bgcolor="#ffffff"
  allowScriptAccess="SameDomain"   ');
document.write(' swLiveConnect=FALSE WIDTH="200px"
  HEIGHT="400px" NAME="MyMovie.swf" ALIGN="right"');
document.write(' TYPE="application/x-shockwave-flash"
  PLUGINSPAGE="http://www.macromedia.com/go/getflashplayer">');
document.write(' </EMBED>');
document.write(' </OBJECT>');
} else{
document.write('<table>');
document.write('    <tr>');
document.write('        <td><span>This is my default content</span></td>');
document.write('    </tr>');
document.write('</table>');
}
//-->
</SCRIPT>
<NOSCRIPT>
<table ID="Table1">
    <tr>
        <td><span>This is my default content</span></td>
    </tr>
</table>
</NOSCRIPT>

HTML View example
------------------

<OSMOSIS:FLASHMOVIE id=FlashMovie1 runat="server"
  MovieName="MyMovie.swf" AutoLoop="False" AutoPlay="False"
MovieScale="NoScale" MovieQuality="AutoLow" FlashHorizontalAlignment="Right"
FlashVerticalAlignment="Top" MovieHeight="222" MovieWidth="33"
WindowMode="Transparent"></Osmosis:FlashMovie>

Thanks for all your input! Keep it coming. Feel free to contact with any questions or suggestions.

History

• Initial release: Up-to-date with Macromedia 2004 properties and output methods.
• 2005/04/12:
  • Enhancement: all properties are maintained in viewstate (except NoScript and NoFlash control properties).
  • Bug fix: should be working better with MAC IE browser (went back to outputting embed tag for all browsers).
  • Bug fix: when using SSL in your movie names, the Macromedia codebase, detection plugins page, and plugins page also use SSL (gets rid of the browser message asking if you want to display non-secure content in a secure page).
• 2004/04/13
  • FSCommand support added.
  • Bug fix: multiple Flash movies on a page supported now (implements INamingContainer).
  • Browser detection: only outputs <embed> tag for non-IE browsers.
• 2005/04/15:
  • Bug fix: added better support for testing for SSL use.
• 2004/05/07:
  Bug fix: fixes last release's problem with not displaying the <embed> tag on MAC IE browsers.
