Thanks for this good implementation.
I did small change in order to allow fully hide the border. In following case in mouse over event, I found that transparent border appeared because was lightened.
Here is my fix for myself
public static Color[] LightenColors(params Color[] colorsToLighten)
{
Color[] colorsToReturn = new Color[colorsToLighten.Length];
for (int i = 0; i < colorsToLighten.Length; i++)
{
if(colorsToLighten[i]==Color.FromKnownColor(KnownColor.Transparent))
colorsToReturn[i] = colorsToLighten[i];
else
colorsToReturn[i] = ControlPaint.Light(colorsToLighten[i]);
}
return colorsToReturn;
}
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
when setting the orientation of the control to vertical, the max value is at the bottom instead of at the top. it's just 180() to what you would expect a normal slider control to be set to in a vertical environment. I am not a great C# coder so can you point me in the right direction to where i can fix this?
thanks! and Awesome control by the way.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
yeah I need this also.
Though a hack you can do is (100 - colorSlider.Value)
modified on Saturday, March 7, 2009 9:09 PM
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
At this point changing that would not be trivial. So it is best to hack it so that instead of using Value property you use (Maximum-Value)
Michał Bryłka
Theory is when you know something, but it doesn't work.
Practice is when something works, but you don't know why.
Programmers combine theory and practice: Nothing works and they don't know why.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
I added the HideOuterRegion property to extend the inner area for the whole control.
In DrawColorSlider method, I check if this property is true and if yes, I don't inflate the barRect in every orientation.
Thanks for great article!
Issahar
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
you're welcome
Michał Bryłka
Theory is when you know something, but it doesn't work.
Practice is when something works, but you don't know why.
Programmers combine theory and practice: Nothing works and they don't know why.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
|
|
|
Thanx
Michał Bryłka
Theory is when you know something, but it doesn't work.
Practice is when something works, but you don't know why.
Programmers combine theory and practice: Nothing works and they don't know why.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
Hi Michal, this is absolutely brilliant and exactly what I was looking for!! Well done! My application is in VB. Could I just place the dll in my solution and reference it or would I need a VB version of the component class?
I tried converting but there are numerous errors!
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
hi,
you only need to extract control source to separate C# library and then add reference to it in your VB project
Regards
Michal Brylka
Theory is when you know something, but it doesn't work.
Practice is when something works, but you don't know why.
Programmers combine theory and practice: Nothing works and they don't know why.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
Good job !
In order to use it in my application i made 2 small modifs:
- I fired the Scroll event after the OnMouse_Wheel
- I added the support for Image Thumb
Here is the changed code of ColorSlider.cs:
using System;
using System.ComponentModel;
using System.Drawing;
using System.Drawing.Drawing2D;
using System.Windows.Forms;
namespace MB.Controls
{
/// <summary>
/// Encapsulates control that visualy displays certain integer value and allows user to change it within desired range. It imitates <see cref="System.Windows.Forms.TrackBar"/> as far as mouse usage is concerned.
/// </summary>
[ToolboxBitmap(typeof(TrackBar))]
[DefaultEvent("Scroll"), DefaultProperty("BarInnerColor")]
public partial class ColorSlider : Control
{
#region Events
/// <summary>
/// Fires when Slider position has changed
/// </summary>
[Description("Event fires when the Value property changes")]
[Category("Action")]
public event EventHandler ValueChanged;
/// <summary>
/// Fires when user scrolls the Slider
/// </summary>
[Description("Event fires when the Slider position is changed")]
[Category("Behavior")]
public event ScrollEventHandler Scroll;
#endregion
#region Properties
private Rectangle thumbRect; //bounding rectangle of thumb area
/// <summary>
/// Gets the thumb rect. Usefull to determine bounding rectangle when creating custom thumb shape.
/// </summary>
/// <value>The thumb rect.</value>
[Browsable(false)]
public Rectangle ThumbRect
{
get { return thumbRect; }
}
private Rectangle barRect; //bounding rectangle of bar area
private Rectangle barHalfRect;
private Rectangle thumbHalfRect;
private Rectangle elapsedRect; //bounding rectangle of elapsed area
private int thumbSize = 15;
/// <summary>
/// Gets or sets the size of the thumb.
/// </summary>
/// <value>The size of the thumb.</value>
/// <exception cref="T:System.ArgumentOutOfRangeException">exception thrown when value is lower than zero or grather than half of appropiate dimension</exception>
[Description("Set Slider thumb size")]
[Category("ColorSlider")]
[DefaultValue(15)]
public int ThumbSize
{
get { return thumbSize; }
set
{
if (value > 0 &
value < (barOrientation == Orientation.Horizontal ? ClientRectangle.Width : ClientRectangle.Height))
thumbSize = value;
else
throw new ArgumentOutOfRangeException(
"TrackSize has to be greather than zero and lower than half of Slider width");
Invalidate();
}
}
private GraphicsPath thumbCustomShape = null;
/// <summary>
/// Gets or sets the thumb custom shape. Use ThumbRect property to determine bounding rectangle.
/// </summary>
/// <value>The thumb custom shape. null means default shape</value>
[Description("Set Slider's thumb's custom shape")]
[Category("ColorSlider")]
[Browsable(false)]
[DefaultValue(typeof(GraphicsPath), "null")]
public GraphicsPath ThumbCustomShape
{
get { return thumbCustomShape; }
set
{
thumbCustomShape = value;
thumbSize = (int) (barOrientation == Orientation.Horizontal ? value.GetBounds().Width : value.GetBounds().Height) + 1;
Invalidate();
}
}
private Size thumbRoundRectSize = new Size(8, 8);
/// <summary>
/// Gets or sets the size of the thumb round rectangle edges.
/// </summary>
/// <value>The size of the thumb round rectangle edges.</value>
[Description("Set Slider's thumb round rect size")]
[Category("ColorSlider")]
[DefaultValue(typeof(Size), "8; 8")]
public Size ThumbRoundRectSize
{
get { return thumbRoundRectSize; }
set
{
int h = value.Height, w = value.Width;
if (h <= 0) h = 1;
if (w <= 0) w = 1;
thumbRoundRectSize = new Size(w, h);
Invalidate();
}
}
private Size borderRoundRectSize = new Size(8, 8);
/// <summary>
/// Gets or sets the size of the border round rect.
/// </summary>
/// <value>The size of the border round rect.</value>
[Description("Set Slider's border round rect size")]
[Category("ColorSlider")]
[DefaultValue(typeof(Size), "8; 8")]
public Size BorderRoundRectSize
{
get { return borderRoundRectSize; }
set
{
int h = value.Height, w = value.Width;
if (h <= 0) h = 1;
if (w <= 0) w = 1;
borderRoundRectSize = new Size(w, h);
Invalidate();
}
}
private Orientation barOrientation = Orientation.Horizontal;
/// <summary>
/// Gets or sets the orientation of Slider.
/// </summary>
/// <value>The orientation.</value>
[Description("Set Slider orientation")]
[Category("ColorSlider")]
[DefaultValue(Orientation.Horizontal)]
public Orientation Orientation
{
get { return barOrientation; }
set
{
if (barOrientation != value)
{
barOrientation = value;
int temp = Width;
Width = Height;
Height = temp;
if (thumbCustomShape != null)
thumbSize =
(int)
(barOrientation == Orientation.Horizontal
? thumbCustomShape.GetBounds().Width
: thumbCustomShape.GetBounds().Height) + 1;
Invalidate();
}
}
}
private int trackerValue = 50;
/// <summary>
/// Gets or sets the value of Slider.
/// </summary>
/// <value>The value.</value>
/// <exception cref="T:System.ArgumentOutOfRangeException">exception thrown when value is outside appropriate range (min, max)</exception>
[Description("Set Slider value")]
[Category("ColorSlider")]
[DefaultValue(50)]
public int Value
{
get { return trackerValue; }
set
{
if (value >= barMinimum & value <= barMaximum)
{
trackerValue = value;
if (ValueChanged != null) ValueChanged(this, new EventArgs());
Invalidate();
}
else throw new ArgumentOutOfRangeException("Value is outside appropriate range (min, max)");
}
}
private int barMinimum = 0;
/// <summary>
/// Gets or sets the minimum value.
/// </summary>
/// <value>The minimum value.</value>
/// <exception cref="T:System.ArgumentOutOfRangeException">exception thrown when minimal value is greather than maximal one</exception>
[Description("Set Slider minimal point")]
[Category("ColorSlider")]
[DefaultValue(0)]
public int Minimum
{
get { return barMinimum; }
set
{
if (value < barMaximum)
{
barMinimum = value;
if (trackerValue < barMinimum)
{
trackerValue = barMinimum;
if (ValueChanged != null) ValueChanged(this, new EventArgs());
}
Invalidate();
}
else throw new ArgumentOutOfRangeException("Minimal value is greather than maximal one");
}
}
private int barMaximum = 100;
/// <summary>
/// Gets or sets the maximum value.
/// </summary>
/// <value>The maximum value.</value>
/// <exception cref="T:System.ArgumentOutOfRangeException">exception thrown when maximal value is lower than minimal one</exception>
[Description("Set Slider maximal point")]
[Category("ColorSlider")]
[DefaultValue(100)]
public int Maximum
{
get { return barMaximum; }
set
{
if (value > barMinimum)
{
barMaximum = value;
if (trackerValue > barMaximum)
{
trackerValue = barMaximum;
if (ValueChanged != null) ValueChanged(this, new EventArgs());
}
Invalidate();
}
else throw new ArgumentOutOfRangeException("Maximal value is lower than minimal one");
}
}
private uint smallChange = 1;
/// <summary>
/// Gets or sets trackbar's small change. It affects how to behave when directional keys are pressed
/// </summary>
/// <value>The small change value.</value>
[Description("Set trackbar's small change")]
[Category("ColorSlider")]
[DefaultValue(1)]
public uint SmallChange
{
get { return smallChange; }
set { smallChange = value; }
}
private uint largeChange = 5;
/// <summary>
/// Gets or sets trackbar's large change. It affects how to behave when PageUp/PageDown keys are pressed
/// </summary>
/// <value>The large change value.</value>
[Description("Set trackbar's large change")]
[Category("ColorSlider")]
[DefaultValue(5)]
public uint LargeChange
{
get { return largeChange; }
set { largeChange = value; }
}
private bool drawFocusRectangle = true;
/// <summary>
/// Gets or sets a value indicating whether to draw focus rectangle.
/// </summary>
/// <value><c>true</c> if focus rectangle should be drawn; otherwise, <c>false</c>.</value>
[Description("Set whether to draw focus rectangle")]
[Category("ColorSlider")]
[DefaultValue(true)]
public bool DrawFocusRectangle
{
get { return drawFocusRectangle; }
set
{
drawFocusRectangle = value;
Invalidate();
}
}
private bool drawSemitransparentThumb = true;
/// <summary>
/// Gets or sets a value indicating whether to draw semitransparent thumb.
/// </summary>
/// <value><c>true</c> if semitransparent thumb should be drawn; otherwise, <c>false</c>.</value>
[Description("Set whether to draw semitransparent thumb")]
[Category("ColorSlider")]
[DefaultValue(true)]
public bool DrawSemitransparentThumb
{
get { return drawSemitransparentThumb; }
set
{
drawSemitransparentThumb = value;
Invalidate();
}
}
private bool mouseEffects = true;
/// <summary>
/// Gets or sets whether mouse entry and exit actions have impact on how control look.
/// </summary>
/// <value><c>true</c> if mouse entry and exit actions have impact on how control look; otherwise, <c>false</c>.</value>
[Description("Set whether mouse entry and exit actions have impact on how control look")]
[Category("ColorSlider")]
[DefaultValue(true)]
public bool MouseEffects
{
get { return mouseEffects; }
set
{
mouseEffects = value;
Invalidate();
}
}
private int mouseWheelBarPartitions = 10;
/// <summary>
/// Gets or sets the mouse wheel bar partitions.
/// </summary>
/// <value>The mouse wheel bar partitions.</value>
/// <exception cref="T:System.ArgumentOutOfRangeException">exception thrown when value isn't greather than zero</exception>
[Description("Set to how many parts is bar divided when using mouse wheel")]
[Category("ColorSlider")]
[DefaultValue(10)]
public int MouseWheelBarPartitions
{
get { return mouseWheelBarPartitions; }
set
{
if (value > 0)
mouseWheelBarPartitions = value;
else throw new ArgumentOutOfRangeException("MouseWheelBarPartitions has to be greather than zero");
}
}
private Image thumbImage = null;
/// <summary>
/// Gets or sets the Image use to render the thumb.
/// </summary>
/// <value>the thumb Image</value>
[Description("Set to use a specific Image for the thumb")]
[Category("ColorSlider")]
[DefaultValue(null)]
public Image ThumbImage
{
get { return thumbImage; }
set
{
if (value !=null )
{
thumbImage = value;
}
}
}
private Color thumbOuterColor = Color.White;
/// <summary>
/// Gets or sets the thumb outer color .
/// </summary>
/// <value>The thumb outer color.</value>
[Description("Set Slider thumb outer color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "White")]
public Color ThumbOuterColor
{
get { return thumbOuterColor; }
set
{
thumbOuterColor = value;
Invalidate();
}
}
private Color thumbInnerColor = Color.Gainsboro;
/// <summary>
/// Gets or sets the inner color of the thumb.
/// </summary>
/// <value>The inner color of the thumb.</value>
[Description("Set Slider thumb inner color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "Gainsboro")]
public Color ThumbInnerColor
{
get { return thumbInnerColor; }
set
{
thumbInnerColor = value;
Invalidate();
}
}
private Color thumbPenColor = Color.Silver;
/// <summary>
/// Gets or sets the color of the thumb pen.
/// </summary>
/// <value>The color of the thumb pen.</value>
[Description("Set Slider thumb pen color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "Silver")]
public Color ThumbPenColor
{
get { return thumbPenColor; }
set
{
thumbPenColor = value;
Invalidate();
}
}
private Color barOuterColor = Color.SkyBlue;
/// <summary>
/// Gets or sets the outer color of the bar.
/// </summary>
/// <value>The outer color of the bar.</value>
[Description("Set Slider bar outer color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "SkyBlue")]
public Color BarOuterColor
{
get { return barOuterColor; }
set
{
barOuterColor = value;
Invalidate();
}
}
private Color barInnerColor = Color.DarkSlateBlue;
/// <summary>
/// Gets or sets the inner color of the bar.
/// </summary>
/// <value>The inner color of the bar.</value>
[Description("Set Slider bar inner color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "DarkSlateBlue")]
public Color BarInnerColor
{
get { return barInnerColor; }
set
{
barInnerColor = value;
Invalidate();
}
}
private Color barPenColor = Color.Gainsboro;
/// <summary>
/// Gets or sets the color of the bar pen.
/// </summary>
/// <value>The color of the bar pen.</value>
[Description("Set Slider bar pen color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "Gainsboro")]
public Color BarPenColor
{
get { return barPenColor; }
set
{
barPenColor = value;
Invalidate();
}
}
private Color elapsedOuterColor = Color.DarkGreen;
/// <summary>
/// Gets or sets the outer color of the elapsed.
/// </summary>
/// <value>The outer color of the elapsed.</value>
[Description("Set Slider's elapsed part outer color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "DarkGreen")]
public Color ElapsedOuterColor
{
get { return elapsedOuterColor; }
set
{
elapsedOuterColor = value;
Invalidate();
}
}
private Color elapsedInnerColor = Color.Chartreuse;
/// <summary>
/// Gets or sets the inner color of the elapsed.
/// </summary>
/// <value>The inner color of the elapsed.</value>
[Description("Set Slider's elapsed part inner color")]
[Category("ColorSlider")]
[DefaultValue(typeof(Color), "Chartreuse")]
public Color ElapsedInnerColor
{
get { return elapsedInnerColor; }
set
{
elapsedInnerColor = value;
Invalidate();
}
}
#endregion
#region Color schemas
//define own color schemas
private Color[,] aColorSchema = new Color[,]
{
{
Color.White, Color.Gainsboro, Color.Silver, Color.SkyBlue, Color.DarkSlateBlue, Color.Gainsboro,
Color.DarkGreen, Color.Chartreuse
},
{
Color.White, Color.Gainsboro, Color.Silver, Color.Red, Color.DarkRed, Color.Gainsboro, Color.Coral,
Color.LightCoral
},
{
Color.White, Color.Gainsboro, Color.Silver, Color.GreenYellow, Color.Yellow, Color.Gold, Color.Orange,
Color.OrangeRed
},
{
Color.White, Color.Gainsboro, Color.Silver, Color.Red, Color.Crimson, Color.Gainsboro, Color.DarkViolet
, Color.Violet
}
};
public enum ColorSchemas
{
PerlBlueGreen,
PerlRedCoral,
PerlGold,
PerlRoyalColors
}
private ColorSchemas colorSchema = ColorSchemas.PerlBlueGreen;
/// <summary>
/// Sets color schema. Color generalization / fast color changing. Has no effect when slider colors are changed manually after schema was applied.
/// </summary>
/// <value>New color schema value</value>
[Description("Set Slider color schema. Has no effect when slider colors are changed manually after schema was applied.")]
[Category("ColorSlider")]
[DefaultValue(typeof(ColorSchemas), "PerlBlueGreen")]
public ColorSchemas ColorSchema
{
get { return colorSchema; }
set
{
colorSchema = value;
byte sn = (byte)value;
thumbOuterColor = aColorSchema[sn, 0];
thumbInnerColor = aColorSchema[sn, 1];
thumbPenColor = aColorSchema[sn, 2];
barOuterColor = aColorSchema[sn, 3];
barInnerColor = aColorSchema[sn, 4];
barPenColor = aColorSchema[sn, 5];
elapsedOuterColor = aColorSchema[sn, 6];
elapsedInnerColor = aColorSchema[sn, 7];
Invalidate();
}
}
#endregion
#region Constructors
/// <summary>
/// Initializes a new instance of the <see cref="ColorSlider"/> class.
/// </summary>
/// <param name="min">The minimum value.</param>
/// <param name="max">The maximum value.</param>
/// <param name="value">The current value.</param>
public ColorSlider(int min, int max, int value)
{
InitializeComponent();
SetStyle(ControlStyles.AllPaintingInWmPaint | ControlStyles.OptimizedDoubleBuffer |
ControlStyles.ResizeRedraw | ControlStyles.Selectable |
ControlStyles.SupportsTransparentBackColor | ControlStyles.UserMouse |
ControlStyles.UserPaint, true);
BackColor = Color.Transparent;
Minimum = min;
Maximum = max;
Value = value;
}
/// <summary>
/// Initializes a new instance of the <see cref="ColorSlider"/> class.
/// </summary>
public ColorSlider() : this(0, 100, 50) { }
#endregion
#region Paint
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.Paint"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.PaintEventArgs"></see> that contains the event data.</param>
protected override void OnPaint(PaintEventArgs e)
{
if (!Enabled)
{
Color[] desaturatedColors = DesaturateColors(thumbOuterColor, thumbInnerColor, thumbPenColor,
barOuterColor, barInnerColor, barPenColor,
elapsedOuterColor, elapsedInnerColor);
DrawColorSlider(e, desaturatedColors[0], desaturatedColors[1], desaturatedColors[2],
desaturatedColors[3],
desaturatedColors[4], desaturatedColors[5], desaturatedColors[6], desaturatedColors[7]);
}
else
{
if (mouseEffects && mouseInRegion)
{
Color[] lightenedColors = LightenColors(thumbOuterColor, thumbInnerColor, thumbPenColor,
barOuterColor, barInnerColor, barPenColor,
elapsedOuterColor, elapsedInnerColor);
DrawColorSlider(e, lightenedColors[0], lightenedColors[1], lightenedColors[2], lightenedColors[3],
lightenedColors[4], lightenedColors[5], lightenedColors[6], lightenedColors[7]);
}
else
{
DrawColorSlider(e, thumbOuterColor, thumbInnerColor, thumbPenColor,
barOuterColor, barInnerColor, barPenColor,
elapsedOuterColor, elapsedInnerColor);
}
}
}
/// <summary>
/// Draws the colorslider control using passed colors.
/// </summary>
/// <param name="e">The <see cref="T:System.Windows.Forms.PaintEventArgs"/> instance containing the event data.</param>
/// <param name="thumbOuterColorPaint">The thumb outer color paint.</param>
/// <param name="thumbInnerColorPaint">The thumb inner color paint.</param>
/// <param name="thumbPenColorPaint">The thumb pen color paint.</param>
/// <param name="barOuterColorPaint">The bar outer color paint.</param>
/// <param name="barInnerColorPaint">The bar inner color paint.</param>
/// <param name="barPenColorPaint">The bar pen color paint.</param>
/// <param name="elapsedOuterColorPaint">The elapsed outer color paint.</param>
/// <param name="elapsedInnerColorPaint">The elapsed inner color paint.</param>
private void DrawColorSlider(PaintEventArgs e, Color thumbOuterColorPaint, Color thumbInnerColorPaint,
Color thumbPenColorPaint, Color barOuterColorPaint, Color barInnerColorPaint,
Color barPenColorPaint, Color elapsedOuterColorPaint, Color elapsedInnerColorPaint)
{
try
{
//set up thumbRect aproprietly
if (barOrientation == Orientation.Horizontal)
{
int TrackX = (((trackerValue - barMinimum) * (ClientRectangle.Width - thumbSize)) / (barMaximum - barMinimum));
thumbRect = new Rectangle(TrackX, 1, thumbSize - 1, ClientRectangle.Height - 3);
}
else
{
int TrackY = (((trackerValue - barMinimum) * (ClientRectangle.Height - thumbSize)) / (barMaximum - barMinimum));
thumbRect = new Rectangle(1, TrackY, ClientRectangle.Width - 3, thumbSize - 1);
}
//adjust drawing rects
barRect = ClientRectangle;
thumbHalfRect = thumbRect;
LinearGradientMode gradientOrientation;
if (barOrientation == Orientation.Horizontal)
{
barRect.Inflate(-1, -barRect.Height / 3);
barHalfRect = barRect;
barHalfRect.Height /= 2;
gradientOrientation = LinearGradientMode.Vertical;
thumbHalfRect.Height /= 2;
elapsedRect = barRect;
elapsedRect.Width = thumbRect.Left + thumbSize / 2;
}
else
{
barRect.Inflate(-barRect.Width / 3, -1);
barHalfRect = barRect;
barHalfRect.Width /= 2;
gradientOrientation = LinearGradientMode.Horizontal;
thumbHalfRect.Width /= 2;
elapsedRect = barRect;
elapsedRect.Height = thumbRect.Top + thumbSize / 2;
}
//get thumb shape path
GraphicsPath thumbPath;
if (thumbCustomShape == null)
thumbPath = CreateRoundRectPath(thumbRect, thumbRoundRectSize);
else
{
thumbPath = thumbCustomShape;
Matrix m = new Matrix();
m.Translate(thumbRect.Left - thumbPath.GetBounds().Left, thumbRect.Top - thumbPath.GetBounds().Top);
thumbPath.Transform(m);
}
//draw bar
using (
LinearGradientBrush lgbBar =
new LinearGradientBrush(barHalfRect, barOuterColorPaint, barInnerColorPaint, gradientOrientation)
)
{
lgbBar.WrapMode = WrapMode.TileFlipXY;
e.Graphics.FillRectangle(lgbBar, barRect);
//draw elapsed bar
using (
LinearGradientBrush lgbElapsed =
new LinearGradientBrush(barHalfRect, elapsedOuterColorPaint, elapsedInnerColorPaint,
gradientOrientation))
{
lgbElapsed.WrapMode = WrapMode.TileFlipXY;
if (Capture && drawSemitransparentThumb)
{
Region elapsedReg = new Region(elapsedRect);
elapsedReg.Exclude(thumbPath);
e.Graphics.FillRegion(lgbElapsed, elapsedReg);
}
else
e.Graphics.FillRectangle(lgbElapsed, elapsedRect);
}
//draw bar band
using (Pen barPen = new Pen(barPenColorPaint, 0.5f))
{
e.Graphics.DrawRectangle(barPen, barRect);
}
}
//draw thumb
Color newthumbOuterColorPaint = thumbOuterColorPaint, newthumbInnerColorPaint = thumbInnerColorPaint;
if (Capture && drawSemitransparentThumb)
{
newthumbOuterColorPaint = Color.FromArgb(175, thumbOuterColorPaint);
newthumbInnerColorPaint = Color.FromArgb(175, thumbInnerColorPaint);
}
using (
LinearGradientBrush lgbThumb =
new LinearGradientBrush(thumbHalfRect, newthumbOuterColorPaint, newthumbInnerColorPaint,
gradientOrientation))
{
lgbThumb.WrapMode = WrapMode.TileFlipXY;
e.Graphics.SmoothingMode = SmoothingMode.AntiAlias;
//draw thumb band
Color newThumbPenColor = thumbPenColorPaint;
if (mouseEffects && (Capture || mouseInThumbRegion))
newThumbPenColor = ControlPaint.Dark(newThumbPenColor);
using (Pen thumbPen = new Pen(newThumbPenColor))
{
if (thumbImage != null)
{
e.Graphics.DrawImage(thumbImage, thumbRect);
}
else
{
e.Graphics.FillPath(lgbThumb, thumbPath);
e.Graphics.DrawPath(thumbPen, thumbPath);
}
}
//gp.Dispose();
/*if (Capture || mouseInThumbRegion)
using (LinearGradientBrush lgbThumb2 = new LinearGradientBrush(thumbHalfRect, Color.FromArgb(150, Color.Blue), Color.Transparent, gradientOrientation))
{
lgbThumb2.WrapMode = WrapMode.TileFlipXY;
e.Graphics.FillPath(lgbThumb2, gp);
}*/
}
//draw focusing rectangle
if (Focused & drawFocusRectangle)
using (Pen p = new Pen(Color.FromArgb(200, barPenColorPaint)))
{
p.DashStyle = DashStyle.Dot;
Rectangle r = ClientRectangle;
r.Width -= 2;
r.Height--;
r.X++;
//ControlPaint.DrawFocusRectangle(e.Graphics, r);
using (GraphicsPath gpBorder = CreateRoundRectPath(r, borderRoundRectSize))
{
e.Graphics.SmoothingMode = SmoothingMode.AntiAlias;
e.Graphics.DrawPath(p, gpBorder);
}
}
}
catch (Exception Err)
{
Console.WriteLine("DrawBackGround Error in " + Name + ":" + Err.Message);
}
finally
{
}
}
#endregion
#region Overided events
private bool mouseInRegion = false;
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.EnabledChanged"></see> event.
/// </summary>
/// <param name="e">An <see cref="T:System.EventArgs"></see> that contains the event data.</param>
protected override void OnEnabledChanged(EventArgs e)
{
base.OnEnabledChanged(e);
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseEnter"></see> event.
/// </summary>
/// <param name="e">An <see cref="T:System.EventArgs"></see> that contains the event data.</param>
protected override void OnMouseEnter(EventArgs e)
{
base.OnMouseEnter(e);
mouseInRegion = true;
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseLeave"></see> event.
/// </summary>
/// <param name="e">An <see cref="T:System.EventArgs"></see> that contains the event data.</param>
protected override void OnMouseLeave(EventArgs e)
{
base.OnMouseLeave(e);
mouseInRegion = false;
mouseInThumbRegion = false;
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseDown"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.MouseEventArgs"></see> that contains the event data.</param>
protected override void OnMouseDown(MouseEventArgs e)
{
base.OnMouseDown(e);
if (e.Button == MouseButtons.Left)
{
Capture = true;
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.ThumbTrack, trackerValue));
if (ValueChanged != null) ValueChanged(this, new EventArgs());
OnMouseMove(e);
}
}
private bool mouseInThumbRegion = false;
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseMove"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.MouseEventArgs"></see> that contains the event data.</param>
protected override void OnMouseMove(MouseEventArgs e)
{
base.OnMouseMove(e);
mouseInThumbRegion = IsPointInRect(e.Location, thumbRect);
if (Capture & e.Button == MouseButtons.Left)
{
ScrollEventType set = ScrollEventType.ThumbPosition;
Point pt = e.Location;
int p = barOrientation == Orientation.Horizontal ? pt.X : pt.Y;
int margin = thumbSize >> 1;
p -= margin;
float coef = (float)(barMaximum - barMinimum) /
(float)
((barOrientation == Orientation.Horizontal ? ClientSize.Width : ClientSize.Height) -
2 * margin);
trackerValue = (int)(p * coef + barMinimum);
if (trackerValue <= barMinimum)
{
trackerValue = barMinimum;
set = ScrollEventType.First;
}
else if (trackerValue >= barMaximum)
{
trackerValue = barMaximum;
set = ScrollEventType.Last;
}
if (Scroll != null) Scroll(this, new ScrollEventArgs(set, trackerValue));
if (ValueChanged != null) ValueChanged(this, new EventArgs());
}
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseUp"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.MouseEventArgs"></see> that contains the event data.</param>
protected override void OnMouseUp(MouseEventArgs e)
{
base.OnMouseUp(e);
Capture = false;
mouseInThumbRegion = IsPointInRect(e.Location, thumbRect);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.EndScroll, trackerValue));
if (ValueChanged != null) ValueChanged(this, new EventArgs());
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.MouseWheel"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.MouseEventArgs"></see> that contains the event data.</param>
protected override void OnMouseWheel(MouseEventArgs e)
{
base.OnMouseWheel(e);
int v = e.Delta / 120 * (barMaximum - barMinimum) / mouseWheelBarPartitions;
SetProperValue(Value + v);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.EndScroll, trackerValue));
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.GotFocus"></see> event.
/// </summary>
/// <param name="e">An <see cref="T:System.EventArgs"></see> that contains the event data.</param>
protected override void OnGotFocus(EventArgs e)
{
base.OnGotFocus(e);
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.LostFocus"></see> event.
/// </summary>
/// <param name="e">An <see cref="T:System.EventArgs"></see> that contains the event data.</param>
protected override void OnLostFocus(EventArgs e)
{
base.OnLostFocus(e);
Invalidate();
}
/// <summary>
/// Raises the <see cref="E:System.Windows.Forms.Control.KeyUp"></see> event.
/// </summary>
/// <param name="e">A <see cref="T:System.Windows.Forms.KeyEventArgs"></see> that contains the event data.</param>
protected override void OnKeyUp(KeyEventArgs e)
{
base.OnKeyUp(e);
switch (e.KeyCode)
{
case Keys.Down:
case Keys.Left:
SetProperValue(Value - (int)smallChange);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.SmallDecrement, Value));
break;
case Keys.Up:
case Keys.Right:
SetProperValue(Value + (int)smallChange);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.SmallIncrement, Value));
break;
case Keys.Home:
Value = barMinimum;
break;
case Keys.End:
Value = barMaximum;
break;
case Keys.PageDown:
SetProperValue(Value - (int)largeChange);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.LargeDecrement, Value));
break;
case Keys.PageUp:
SetProperValue(Value + (int)largeChange);
if (Scroll != null) Scroll(this, new ScrollEventArgs(ScrollEventType.LargeIncrement, Value));
break;
}
if (Scroll != null && Value == barMinimum) Scroll(this, new ScrollEventArgs(ScrollEventType.First, Value));
if (Scroll != null && Value == barMaximum) Scroll(this, new ScrollEventArgs(ScrollEventType.Last, Value));
Point pt = PointToClient(Cursor.Position);
OnMouseMove(new MouseEventArgs(MouseButtons.None, 0, pt.X, pt.Y, 0));
}
/// <summary>
/// Processes a dialog key.
/// </summary>
/// <param name="keyData">One of the <see cref="T:System.Windows.Forms.Keys"></see> values that represents the key to process.</param>
/// <returns>
/// true if the key was processed by the control; otherwise, false.
/// </returns>
protected override bool ProcessDialogKey(Keys keyData)
{
if (keyData == Keys.Tab | ModifierKeys == Keys.Shift)
return base.ProcessDialogKey(keyData);
else
{
OnKeyDown(new KeyEventArgs(keyData));
return true;
}
}
#endregion
#region Help routines
/// <summary>
/// Creates the round rect path.
/// </summary>
/// <param name="rect">The rectangle on which graphics path will be spanned.</param>
/// <param name="size">The size of rounded rectangle edges.</param>
/// <returns></returns>
public static GraphicsPath CreateRoundRectPath(Rectangle rect, Size size)
{
GraphicsPath gp = new GraphicsPath();
gp.AddLine(rect.Left + size.Width / 2, rect.Top, rect.Right - size.Width / 2, rect.Top);
gp.AddArc(rect.Right - size.Width, rect.Top, size.Width, size.Height, 270, 90);
gp.AddLine(rect.Right, rect.Top + size.Height / 2, rect.Right, rect.Bottom - size.Width / 2);
gp.AddArc(rect.Right - size.Width, rect.Bottom - size.Height, size.Width, size.Height, 0, 90);
gp.AddLine(rect.Right - size.Width / 2, rect.Bottom, rect.Left + size.Width / 2, rect.Bottom);
gp.AddArc(rect.Left, rect.Bottom - size.Height, size.Width, size.Height, 90, 90);
gp.AddLine(rect.Left, rect.Bottom - size.Height / 2, rect.Left, rect.Top + size.Height / 2);
gp.AddArc(rect.Left, rect.Top, size.Width, size.Height, 180, 90);
return gp;
}
/// <summary>
/// Desaturates colors from given array.
/// </summary>
/// <param name="colorsToDesaturate">The colors to be desaturated.</param>
/// <returns></returns>
public static Color[] DesaturateColors(params Color[] colorsToDesaturate)
{
Color[] colorsToReturn = new Color[colorsToDesaturate.Length];
for (int i = 0; i < colorsToDesaturate.Length; i++)
{
//use NTSC weighted avarage
int gray =
(int)(colorsToDesaturate[i].R * 0.3 + colorsToDesaturate[i].G * 0.6 + colorsToDesaturate[i].B * 0.1);
colorsToReturn[i] = Color.FromArgb(-0x010101 * (255 - gray) - 1);
}
return colorsToReturn;
}
/// <summary>
/// Lightens colors from given array.
/// </summary>
/// <param name="colorsToLighten">The colors to lighten.</param>
/// <returns></returns>
public static Color[] LightenColors(params Color[] colorsToLighten)
{
Color[] colorsToReturn = new Color[colorsToLighten.Length];
for (int i = 0; i < colorsToLighten.Length; i++)
{
colorsToReturn[i] = ControlPaint.Light(colorsToLighten[i]);
}
return colorsToReturn;
}
/// <summary>
/// Sets the trackbar value so that it wont exceed allowed range.
/// </summary>
/// <param name="val">The value.</param>
private void SetProperValue(int val)
{
if (val < barMinimum) Value = barMinimum;
else if (val > barMaximum) Value = barMaximum;
else Value = val;
}
/// <summary>
/// Determines whether rectangle contains given point.
/// </summary>
/// <param name="pt">The point to test.</param>
/// <param name="rect">The base rectangle.</param>
/// <returns>
/// <c>true</c> if rectangle contains given point; otherwise, <c>false</c>.
/// </returns>
private static bool IsPointInRect(Point pt, Rectangle rect)
{
if (pt.X > rect.Left & pt.X < rect.Right & pt.Y > rect.Top & pt.Y < rect.Bottom)
return true;
else return false;
}
#endregion
}
}
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
Thanks, nice job
Michal Brylka
Theory is when you know something, but it doesn't work.
Practice is when something works, but you don't know why.
Programmers combine theory and practice: Nothing works and they don't know why.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
This is an excellent control, thanks. I made two small changes for my project. The focus rectangle was being rendered too faintly so I needed to change its color. It may be useful to have its color as a separate color property. I also moved the focus rendering code before the knob rendering because the rectangle was being rendered on top of the knob which did not look right at all.
Ever think of doing a good bitmap button control? I could use one of those too.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
Hey dude great control... is there a way to have multiple track points that you can slide on the same tab strip?
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
yes, there is such possibility, I even wanted to implement such capability (ie. RangeBar), however I never had time to do so.
Michał Bryłka
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
First of all thanks for your work. This is a very good Slidercontrol.
I am in need for such a control for use in a toolbar. I tried different existing versions plus used ToolStripControlHost with TrackBar to implement one on my own but I either had performance issues (flickering, etc) or simply could not make the TrackBar leave overwriting the ToolStripBackground (even with transparent background).
Finally I saw your control, took the code and inherited your control from ToolStripItem instead of Control. The few changes needed were made fast and now I got a pretty highly customizable slidercontrol .
Thanks.
P.S.: I would like to send you the changed code, but could not find your email.
|
| Sign In·View Thread·PermaLink | 2.00/5 (1 vote) |
|
|
|
|
|
|
Hi,
nice to hear that somebody is interested in my control.
If you'd like to send me your code, feel free to do so, I'd appreciate it; here is my email:
michal.brylka[you-know-what-comes-here-at_sign]op.pl
Regards and thanks in advance
Michal Brylka
modified on Friday, February 22, 2008 8:45 AM
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
sorry,my english is poor.
your control is exactly what i was looking for.
But i want this trackbar have two blocks to Restrictions a scope,i shoud how to modify your code?
Thank you very much.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
|
|
|
Just wanted to spread my new acquited nighmare. Shouldn't all custom controls implement accessibility?
/Xav
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
|
|
|
Well, not realy... but I know in your components case it should be about defining interactive areas (like the large change click and the slider itself etc). And report their position, name and funtions. The technology exists and is easily implemented i Visual Studio 2003/2005.
- Good luck!
/Xav
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
Well - an interesting idea, and well presented. Congratulations.
Have you looked into WPF? If you could do this in WPF and post an article on it, then I for one would certainly be interested.
Anyway, 5 out 5 from me.
the last thing I want to see is some pasty-faced geek with skin so pale that it's almost translucent trying to bump parts with a partner - John Simmons / outlaw programmer
Deja View - the feeling that you've seen this post before.
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
I'm installing Vista as soon as it is available at MSDN AA. I'll then take a glance at WPF. Hopefully I'll be able to catch with this technology.
Michał Bryłka
|
| Sign In·View Thread·PermaLink | |
|
|
|
|
|
|
There are fiew things that could be done and which will put your fader into
the ultimate fader I will soon code if not finding it...
Theses functionnalities are :
Able to set the image for the Background
Able to set the image for the bar in the middle (define also its position)
able to set a list of Tick... (this could allow us to put them where we want)
Thanks
The Monz, Toulouse, France
|
| Sign In·View Thread·PermaLink | 2.00/5 (1 vote) |
|
|
|
|
|
General
News
Question
Answer
Joke
Rant
Admin
