GIS data visualization of VisualBasic hybrids with SVG/CSS

Rate this:
Please Sign up or sign in to vote.
The new VB.NET language that applied in data science.

For the furthering developement of this program, install the Microsoft VisualBasic CLI App runtime from nuget at first:

PM> Install-Package VB_AppFramework -Pre

And then add reference to these dll modules:

  • Microsoft.VisualBasic.Architecture.Framework_v3.0_22.0.76.201__8da45dcd8060cc9a.dll
  • Microsoft.VisualBasic.Data.Csv.dll
  • Microsoft.VisualBasic.Imaging.dll
  • Microsoft.VisualBasic.MIME.Markup.dll

Acknowledgement

All of the programming idea in this post comes from this article on website VISUAL CINNAMON

Showing Life Expectancy around the World: http://www.visualcinnamon.com/2013/03/showing-life-expectancy-around-world.html

Using the Code

1. The blank world map SVG

Quote:

source from wiki: File:BlankMap-World6.svg

Here is the blank map data that i download from wiki and makes some tweaks: removes the small region circle to solve the GIMP rendering problem and removes the oceans drawing Polygon path data, so that the final map it looks like:

This modified blank map svg data can be found at my github repository: https://github.com/xieguigang/Data.GIS/blob/master/data/BlankMap-World6.svg

2. How to rendering the colors on SVG Polygon?

From the observation on the data structure of the SVG elements in the blank world map data, that we can know that all of the svg graphics object g and polygon object path have the style attribute for applying CSS style and id attribute for identify the country or region object, here is a example of the svg document:

<g style="fill: rgb(204,0,0);" id="fr">
   ...
   <path style="fill: rgb(204,0,0);" class="landxx fr gf eu" id="gf" d="..." />
   <title>France</title>
</g>

So that all we needs to do just found the country or region object by using the id attribute and then calculate the mapped color for that object and set the CSS value string to the style attribute, that we can done our job on this rendering work.

3. The color renderer

Using ISO-3166_1 found svg object

The polygon object in the blank world map SVG is using the iso-3166 alpha2 code as identifier, but the problem is that in the most situation that we input the data is using the country name not this brief code, so that we just using a dictionary to translate the country name or other brief code to the required iso-3166 alpha2 code:

Imports Microsoft.VisualBasic.Serialization.JSON

Public Class ISO_3166

    Public Property name As String
    Public Property alpha2 As String
    Public Property alpha3 As String
    Public Property code As String

    Public Overrides Function ToString() As String
        Return Me.GetJson
    End Function
End Class

And by creates this dictionary will makes the input country name compatible with all fields in the ISO-3166_1 data. And then by using this dictionary that we can translate the input keyword as the iso-3166-1 alpha2 code for finding the svg graphics or path object.

Public ReadOnly statDict As Dictionary(Of String, String)

statDict = (From x As ISO_3166
            In __iso_3166
            Select {
                x.name.ToLower,
                x.alpha2,
                x.alpha3,
                x.code}.Select(Function(code) New With {
                    .code = code,
                    .alpha2 = x.alpha2
                })).MatrixAsIterator.ToDictionary(
                    Function(x) x.code,
                    Function(x) x.alpha2)

So that by using the iso-3166 alpha2 code, that we can found any country object in the map svg data by using the code below:

''' <summary>
''' thanks to the XML/HTML style of the SVG (and Nathan’s explanation) I can create CSS
''' classes per country
''' (the polygons of each country uses the alpha-2 country code as a class id)
''' </summary>
''' <param name="map"></param>
''' <param name="code"></param>
''' <returns></returns>
<Extension>
Private Function __country(map As SVGXml, code As String) As node
    Dim alpha2 As String =
        If(statDict.ContainsKey(code),
        statDict(code),
        statDict.TryGetValue(code.ToLower))
    Dim c As node = map.gs.__country(alpha2)

    If c Is Nothing Then
        c = map.path.__country(alpha2)

        If c Is Nothing Then
            Call $"Unable found Object named '{code}'!".PrintException
        End If
    End If

    Return c
End Function

<Extension>
Private Function __country(subs As path(), alpha2 As String) As path
    For Each path As path In subs.SafeQuery
        If path.id.TextEquals(alpha2) Then
            Return path
        End If
    Next

    Return Nothing
End Function

<Extension>
Private Function __country(subs As g(), alpha2 As String) As node
    Dim state As New Value(Of node)

    For Each c As g In subs
        If alpha2.TextEquals(c.id) Then
            Return c
        Else
            If c.gs.IsNullOrEmpty Then
                Continue For
            End If
        End If

        If Not (state = c.gs.__country(alpha2)) Is Nothing Then
            Return state
        End If

        If Not (state = c.path.__country(alpha2)) Is Nothing Then
            Return state  ' fix error for GF island
        End If
    Next

    Return Nothing
End Function

Level Mappings

By measure the difference of value x with the minimum value of the vector elements, and then calculate the proportion by Divided the difference with the extreme distance of the max and min value in the input vector, that we can do a linear scale mapping of the input data:

For Each x As Double In array
    Dim lv As Integer = CInt(Level * (x - MinValue) / d)
    chunkBuf(++i) = lv + offset
Next

Here is the linear mapping function that defined in VisualBasic: Microsoft.VisualBasic.Mathematical::ScaleMaps.GenerateMapping(System.Collections.Generic.IEnumerable(Of Double), Integer, Integer) As Integer()

''' <summary>
''' Linear mappings the vector elements in to another scale within specifc range from
''' parameter <paramref name="Level"></paramref>.
''' </summary>
''' <param name="data">Your input numeric vector.</param>
''' <param name="Level">The scaler range.</param>
''' <returns></returns>
''' <param name="offset">
''' The default scaler range output is [1, <paramref name="Level"></paramref>],
''' but you can modify this parameter value for moving the range to
''' [<paramref name="offset"></paramref>, <paramref name="Level"></paramref> +
''' <paramref name="offset"></paramref>].
''' </param>
<ExportAPI("Ranks.Mapping")>
<Extension> Public Function GenerateMapping(data As IEnumerable(Of Double), Optional Level As Integer = 10, Optional offset As Integer = 1) As Integer()
    Dim array As Double() = data.ToArray
    Dim MinValue As Double = array.Min
    Dim MaxValue As Double = array.Max
    Dim d As Double = MaxValue - MinValue

    If d = 0R Then
        Return 1.CopyVector(array.Length)
    End If

    Dim chunkBuf As Integer() = New Integer(array.Length - 1) {}
    Dim i As int = 0

    For Each x As Double In array
        Dim lv As Integer = CInt(Level * (x - MinValue) / d)
        chunkBuf(++i) = lv + offset
    Next

    Return chunkBuf
End Function

Generates the color patterns

The color maps in this tools have eight patterns, which can be assign from the renderer function's mapName parameter:

''' <summary>
''' Spring
''' </summary>
Public Const PatternSpring As String = "Spring"
''' <summary>
''' Summer
''' </summary>
Public Const PatternSummer As String = "Summer"
''' <summary>
''' Autumn
''' </summary>
Public Const PatternAutumn As String = "Autumn"
''' <summary>
''' Winter
''' </summary>
Public Const PatternWinter As String = "Winter"
''' <summary>
''' Jet
''' </summary>
Public Const PatternJet As String = "Jet"
''' <summary>
''' Gray
''' </summary>
Public Const PatternGray As String = "Gray"
''' <summary>
''' Hot
''' </summary>
Public Const PatternHot As String = "Hot"
''' <summary>
''' Cool
''' </summary>
Public Const PatternCool As String = "Cool"

The color pattern generated code can be found at this codeproject article:

Quote:

"Create Custom Color Maps in C#": http://www.codeproject.com/Articles/18150/Create-Custom-Color-Maps-in-C

And also additional three color pattern are provides from this R script result, and the render function using this R generated color pattern with 256 mapping level depth:

require(fields)

# Loading required package: fields
# Loading required package: spam
# Loading required package: grid
# Spam version 1.3-0 (2015-10-24) is loaded.
# Type 'help( Spam)' or 'demo( spam)' for a short introduction
# and overview of this package.
# Help for individual functions is also obtained by adding the
# suffix '.spam' to the function name, e.g. 'help( chol.spam)'.
#
# Attaching package: ‘spam’
#
# The following objects are masked from ‘package:base’:
#
#     backsolve, forwardsolve
#
# Loading required package: maps
#
#   maps v3.1: updated 'world': all lakes moved to separate new #
#   'lakes' database. Type '?world' or 'news(package="maps")'.  #

designer.colors(n=10, col=c("#CCEBC5", "#A8DDB5", "#7BCCC4", "#4EB3D3", "#08589E", "#08589E"))
designer.colors(n=256, col=c("#CCEBC5", "#A8DDB5", "#7BCCC4", "#4EB3D3", "#08589E", "#08589E"))
designer.colors(n=512, col=c("#CCEBC5", "#A8DDB5", "#7BCCC4", "#4EB3D3", "#08589E", "#08589E"))

Fill color on ploygon

As we've described above, all of the graphics and path object in the SVG image that have a attribute for applied the CSS style which is named style, so that we just assign the CSS fill style into this attribute that we can fill the specific color into the target polygon object, here is the code:

<Extension> Public Sub FillColor(ByRef g As node, color As String)
    g.style = $"fill: {color};"  ' path/g

    If TypeOf g Is g Then
        Dim x As g = DirectCast(g, g)

        For Each [sub] As g In x.gs.SafeQuery
            Call [sub].FillColor(color)
        Next

        For Each path As path In x.path.SafeQuery
            path.style = g.style
        Next
    End If
End Sub

Insert image into SVG

Finally we can rendering the map with various colors, and we needs a legend to indicates that what the meaning of these color. Drawing a legend by using gdi+ is super easy and embedded this generated legend image into the Svg image is also easy. About how to embedded the image into SVG, please review on this stackoverflow problem: http://stackoverflow.com/questions/6249664/does-svg-support-embedding-of-bitmap-images

Here is the svg image object that define in VisualBasic language:

Public Class Image

    <XmlAttribute> Public Property x As Double
    <XmlAttribute> Public Property y As Double
    <XmlAttribute> Public Property width As String
    <XmlAttribute> Public Property height As String
    <XmlAttribute("image.data")> Public Property data As String

    ''' <summary>
    ''' </summary>

    Sub New()
    End Sub

    Sub New(image As Bitmap, Optional size As Size = Nothing)
        data = base64Header & image.ToBase64String
        If size.IsEmpty Then
            size = image.Size
        End If
        width = size.Width
        height = size.Height
    End Sub
End Class

And after the legend image was output from the DrawLegend function, that we can creates a svg image object and put on the specific position on the svg Image by calculating the x and y position value.

legend = designer.DrawLegend(title)
renderedMap.images = {
    New SVG.Image(legend) With {
        .height = legend.Height * 0.5,
        .width = legend.Width * 0.5,
        .x = .width / 2,
        .y = renderedMap.height - .height
    }
}

Example

A demo CLI tools for this map color rendering module can be found in the attachments.

CLI tool

<ExportAPI("/Rendering",
           Usage:="/Rendering /in <data.csv> [/main <title> /legend.title <legend title> /map.levels <512> /map <map.svg> /map.Name <default> /out <out.svg>]")>
<ParameterInfo("/in", False,
               AcceptTypes:={GetType(Data)},
               Description:="A data file template example can be found in the ./Templates/ folder.")>
<ParameterInfo("/map.levels", True, AcceptTypes:={GetType(Integer)},
               Description:="Any positive integer value, this will adjust the color depth for the value mappings.")>
<ParameterInfo("/map", True,
               Description:="User custom map svg, please note that the id attribute of the ``g`` or ``path`` object in the svg stands for the country for region should be the iso-3166-1 alpha2 code.")>
<ParameterInfo("/map.Name", True, AcceptTypes:={GetType(String)},
               Description:="The color map pattern profile name, the VisualBasic language build in color patterns name can be found at github: https://github.com/xieguigang/VisualBasic_AppFramework/tree/master/gr
               And this value is set as ``default`` if this parameter is not specified, in this situation, the parameter value of /map.levels is only allowd 256 or 512.")>
Public Function Rendering(args As CommandLine) As Integer
    Dim [in] As String = args("/in")
    Dim map As String = args("/map")
    Dim iso_3166 As String = args("/iso_3166")
    Dim levels As Integer = args.GetValue("/map.levels", 512)
    Dim mapName As String = args.GetValue("/map.Name", "default")
    Dim main As String = args("/main")
    Dim out As String = args.GetValue(
        "/out",
        [in].TrimSuffix & $".rendering;levels={levels},map.Name={mapName}.svg")
    Dim data As IEnumerable(Of Data) = [in].LoadCsv(Of Data)
    Dim legend As Bitmap = Nothing
    Dim legendTitle As String = args.GetValue("/legend.title", "Legend title")
    Dim svg As SVGXml = data.Rendering(
        levels,
        mapTemplate:=map.ReadAllText(throwEx:=False, suppress:=True),
        mapName:=mapName,
        legend:=legend,
        title:=legendTitle)
    If Not String.IsNullOrEmpty(main) Then
        svg.title = main
    End If
    Return svg.SaveAsXml(out).CLICode
End Function

CLI usage

GIS_render /Rendering /in <data.csv> [/main <title> /legend.title <legend title> /map.levels <512> /map <map.svg> /iso_3166 <iso_3166.csv> /map.Name <default> /out <out.svg>]

Gallery

Test Data: Life expectancy at birth, male (years)

API_SP.DYN.LE00.MA.IN_DS2_en_csv_v2 data was download from worldbank: http://data.worldbank.org/indicator/SP.DYN.LE00.MA.IN using year 2012 as Data.value

#!/bin/bash

../GIS_render.exe /rendering /in ./API_SP.DYN.LE00.MA.IN_DS2.csv /map.name Summer /map.levels 512
../GIS_render.exe /rendering /in ./API_SP.DYN.LE00.MA.IN_DS2.csv /map.name Jet /map.levels 20
Test rendering with /map.levels = 512; /map.Name = Summer

Test rendering with /map.levels = 20; /map.Name = Jet

Test On Linux

The example CLI tools have been test successful on Ubuntu system:

License

This article, along with any associated source code and files, is licensed under The Code Project Open License (CPOL)

Share

About the Author

Mr. xieguigang 谢桂纲
Student 中国南方微生物资源利用中心(SMRUCC)
China China
He is good and loves VisualBasic!



github: https://github.com/xieguigang

You may also be interested in...

Pro

Comments and Discussions


-- There are no messages in this forum --
Permalink | Advertise | Privacy | Cookies | Terms of Use | Mobile
Web01 | 2.8.181215.1 | Last Updated 26 Sep 2016
Article Copyright 2016 by Mr. xieguigang 谢桂纲
Everything else Copyright © CodeProject, 1999-2018
Layout: fixed | fluid
