ASP.NET Application and Page Life Cycle

4.92/5 (401 votes)
8 Feb 2013CPOL12 min read 25   11.9K
ASP.NET application and page life cycle

Table of Contents

Can you explain ASP.NET application and page life cycle-(Demo, in which event we should do what) Part 3?Image 1

Introduction

In this article, we will try to understand what the different events are which take place right from the time the user sends a request, until the time the request is rendered on the browser. So we will first try to understand the two broader steps of an ASP.NET request and then we will move into different events emitted from ‘HttpHandler’, ‘HttpModule’ and ASP.NET page object. As we move in this event journey, we will try to understand what kind of logic should go in each and every one of these events.

The Two Step Process

From 30,000 feet level, ASP.NET request processing is a 2 step process as shown below. User sends a request to the IIS:

  • ASP.NET creates an environment which can process the request. In other words, it creates the application object, request, response and context objects to process the request.
  • Once the environment is created, the request is processed through a series of events which is processed by using modules, handlers and page objects. To keep it short, let's name this step as MHPM (Module, handler, page and Module event), we will come to details later.

Image 2

In the coming sections, we will understand both these main steps in more detail.

Creation of ASP.NET Environment

Step 1: The user sends a request to IIS. IIS first checks which ISAPI extension can serve this request. Depending on file extension the request is processed. For instance, if the page is an ‘.ASPX page’, then it will be passed to ‘aspnet_isapi.dll’ for processing.

Step 2: If this is the first request to the website, then a class called as ‘ApplicationManager’ creates an application domain where the website can run. As we all know, the application domain creates isolation between two web applications hosted on the same IIS. So in case there is an issue in one app domain, it does not affect the other app domain.

Step 3: The newly created application domain creates hosting environment, i.e. the ‘HttpRuntime’ object. Once the hosting environment is created, the necessary core ASP.NET objects like ‘HttpContext’ , ‘HttpRequest’ and ‘HttpResponse’ objects are created.

Step 4: Once all the core ASP.NET objects are created, ‘HttpApplication’ object is created to serve the request. In case you have a ‘global.asax’ file in your system, then the object of the ‘global.asax’ file will be created. Please note global.asax file inherits from ‘HttpApplication’ class.
Note: The first time an ASP.NET page is attached to an application, a new instance of ‘HttpApplication’ is created. Said and done to maximize performance, HttpApplication instances might be reused for multiple requests.

Step 5: The HttpApplication object is then assigned to the core ASP.NET objects to process the page.

Step 6: HttpApplication then starts processing the request by HTTP module events, handlers and page events. It fires the MHPM event for request processing.
Note: For more details, read this.

Image 3

The below image explains how the internal object model looks like for an ASP.NET request. At the top level is the ASP.NET runtime which creates an ‘Appdomain’ which in turn has ‘HttpRuntime’ with ‘request’, ‘response’ and ‘context’ objects.

Image 4

Process Request using MHPM Events Fired

Once ‘HttpApplication’ is created, it starts processing requests. It goes through 3 different sections ‘HttpModule’ , ‘Page’ and ‘HttpHandler’. As it moves through these sections, it invokes different events which the developer can extend and add customize logic to the same.
Before we move ahead, let's understand what are ‘HttpModule’ and ‘HttpHandlers’. They help us to inject custom logic before and after the ASP.NET page is processed. The main differences between both of them are:

  • If you want to inject logic based in file extensions like ‘.ASPX’, ‘.HTML’, then you use ‘HttpHandler’. In other words, ‘HttpHandler’ is an extension based processor.

    Image 5

  • If you want to inject logic in the events of ASP.NET pipleline, then you use ‘HttpModule’. ASP.NET. In other words, ‘HttpModule’ is an event based processor.

    Image 6

You can read more about the differences from here.
Below is the logical flow of how the request is processed. There are 4 important steps MHPM as explained below:

Step 1(M: HttpModule): Client request processing starts. Before the ASP.NET engine goes and creates the ASP.NET HttpModule emits events which can be used to inject customized logic. There are 6 important events which you can utilize before your page object is created BeginRequest, AuthenticateRequest, AuthorizeRequest, ResolveRequestCache, AcquireRequestState and PreRequestHandlerExecute.

Step 2 (H: ‘HttpHandler’): Once the above 6 events are fired, ASP.NET engine will invoke ProcessRequest event if you have implemented HttpHandler in your project.

Step 3 (P: ASP.NET page): Once the HttpHandler logic executes, the ASP.NET page object is created. While the ASP.NET page object is created, many events are fired which can help us to write our custom logic inside those page events. There are 6 important events which provides us placeholder to write logic inside ASP.NET pages Init, Load, validate, event, render and unload. You can remember the word SILVER to remember the events S – Start (does not signify anything as such just forms the word) , I – (Init) , L (Load) , V (Validate), E (Event) and R (Render).

Step4 (M: HttpModule): Once the page object is executed and unloaded from memory, HttpModule provides post page execution events which can be used to inject custom post-processing logic. There are 4 important post-processing events PostRequestHandlerExecute, ReleaserequestState, UpdateRequestCache and EndRequest.
The below figure shows the same in a pictorial format.

Image 7

In What Event Should We Do What?

The million dollar question is in which events should we do what? Below is the table which shows in which event what kind of logic or code can go.

Section Event Description
HttpModule BeginRequest This event signals a new request; it is guaranteed to be raised on each request.
HttpModule AuthenticateRequest This event signals that ASP.NET runtime is ready to authenticate the user. Any authentication code can be injected here.
HttpModule AuthorizeRequest This event signals that ASP.NET runtime is ready to authorize the user. Any authorization code can be injected here.
HttpModule ResolveRequestCache In ASP.NET, we normally use outputcache directive to do caching. In this event, ASP.NET runtime determines if the page can be served from the cache rather than loading the patch from scratch. Any caching specific activity can be injected here.
HttpModule AcquireRequestState This event signals that ASP.NET runtime is ready to acquire session variables. Any processing you would like to do on session variables.
HttpModule PreRequestHandlerExecute This event is raised just prior to handling control to the HttpHandler. Before you want the control to be handed over to the handler any pre-processing you would like to do.
HttpHandler ProcessRequest Httphandler logic is executed. In this section, we will write logic which needs to be executed as per page extensions.
Page Init This event happens in the ASP.NET page and can be used for:
  • Creating controls dynamically, in case you have controls to be created on runtime.
  • Any setting initialization.
  • Master pages and the settings.

In this section, we do not have access to viewstate, postedvalues and neither the controls are initialized.

Page Load In this section, the ASP.NET controls are fully loaded and you write UI manipulation logic or any other logic over here.
Page Validate If you have valuators on your page, you would like to check the same here.
  Render It’s now time to send the output to the browser. If you would like to make some changes to the final HTML which is going out to the browser, you can enter your HTML logic here.
Page Unload Page object is unloaded from the memory.
HttpModule PostRequestHandlerExecute Any logic you would like to inject after the handlers are executed.
HttpModule ReleaserequestState If you would like to save update some state variables like session variables.
HttpModule UpdateRequestCache Before you end, if you want to update your cache.
HttpModule EndRequest This is the last stage before your output is sent to the client browser.

A Sample Code for Demonstration

With this article, we have attached a sample code which shows how the events actually fire. In this code, we have created a ‘HttpModule’ and ‘Httphandler’ in this project and we have displayed a simple response write in all events, below is how the output looks like.
Below is the class for ‘HttpModule’ which tracks all events and adds it to a global collection.

C#
public class clsHttpModule : IHttpModule
{
......
void OnUpdateRequestCache(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnUpdateRequestCache");
}
void OnReleaseRequestState(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnReleaseRequestState");
}
void OnPostRequestHandlerExecute(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnPostRequestHandlerExecute");
}
void OnPreRequestHandlerExecute(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnPreRequestHandlerExecute");
}
void OnAcquireRequestState(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnAcquireRequestState");
}
void OnResolveRequestCache(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnResolveRequestCache");
}
void OnAuthorization(object sender, EventArgs a)
{
objArrayList.Add("httpModule:OnAuthorization");
}
void OnAuthentication(object sender, EventArgs a)
{

objArrayList.Add("httpModule:AuthenticateRequest");
}
void OnBeginrequest(object sender, EventArgs a)
{

objArrayList.Add("httpModule:BeginRequest");
}
void OnEndRequest(object sender, EventArgs a)
{
objArrayList.Add("httpModule:EndRequest");
objArrayList.Add("<hr>");
foreach (string str in objArrayList)
{
httpApp.Context.Response.Write(str + "<br>") ;
}
}
}

Below is the code snippet for ‘HttpHandler’ which tracks ‘ProcessRequest’ event.

C#
public class clsHttpHandler : IHttpHandler
{
public void ProcessRequest(HttpContext context)
{
clsHttpModule.objArrayList.Add("HttpHandler:ProcessRequest");
context.Response.Redirect("Default.aspx");
}
}

We are also tracking all the events from the ASP.NET page.

C#
public partial class _Default : System.Web.UI.Page
{
protected void Page_init(object sender, EventArgs e)
{

clsHttpModule.objArrayList.Add("Page:Init");
}
protected void Page_Load(object sender, EventArgs e)
{
clsHttpModule.objArrayList.Add("Page:Load");
}
public override void Validate()
{
clsHttpModule.objArrayList.Add("Page:Validate");
}
protected void Button1_Click(object sender, EventArgs e)
{
clsHttpModule.objArrayList.Add("Page:Event");
}
protected override void Render(HtmlTextWriter output)
{
clsHttpModule.objArrayList.Add("Page:Render");
base.Render(output);
}
protected void Page_Unload(object sender, EventArgs e)
{
clsHttpModule.objArrayList.Add("Page:UnLoad");
}}

Below is how the display looks like with all events as per the sequence discussed in the previous section.

Image 8

Zooming ASP.NET Page Events

In the above section, we have seen the overall flow of events for an ASP.NET page request. One of the most important sections is the ASP.NET page, we have not discussed the same in detail. So let’s take some luxury to describe the ASP.NET page events in more detail in this section.

Any ASP.NET page has 2 parts, one is the page which is displayed on the browser which has HTML tags, hidden values in form of viewstate and data on the HTML inputs. When the page is posted, these HTML tags are created in to ASP.NET controls with viewstate and form data tied up together on the server. Once you get these full server controls on the behind code, you can execute and write your own login on the same and render the page back to the browser.

Image 9

Now between these HTML controls coming live on the server as ASP.NET controls, the ASP.NET page emits out lot of events which can be consumed to inject logic. Depending on what task / logic you want to perform, we need to put this logic appropriately in those events.
Note: Most of the developers directly use the page_load method for everything, which is not a good thought. So it’s either populating the controls, setting view state, applying themes, etc., everything happens on the page load. So if we can put logic in proper events as per the nature of the logic, that would really make your code clean.

Seq Events Controls Initialized View state
Available
Form data
Available
What Logic can be written here?
1 Init No No No

Note: You can access form data etc. by using ASP.NET request objects but not by Server controls.Creating controls dynamically, in case you have controls to be created on runtime. Any setting initialization.Master pages and them settings. In this section, we do not have access to viewstate , posted values and neither the controls are initialized.

2 Load view state Not guaranteed Yes Not guaranteed You can access view state and any synch logic where you want viewstate to be pushed to behind code variables can be done here.
3 PostBackdata Not guaranteed Yes Yes You can access form data. Any logic where you want the form data to be pushed to behind code variables can be done here.
4 Load Yes Yes Yes This is the place where you will put any logic you want to operate on the controls. Like flourishing a combobox from the database, sorting data on a grid, etc. In this event, we get access to all controls, viewstate and their posted values.
5 Validate Yes Yes Yes If your page has validators or you want to execute validation for your page, this is the right place to the same.
6 Event Yes Yes Yes If this is a post back by a button click or a dropdown change, then the relative events will be fired. Any kind of logic which is related to that event can be executed here.
7 Pre-render Yes Yes Yes If you want to make final changes to the UI objects like changing tree structure or property values, before these controls are saved in to view state.
8 Save view state Yes Yes Yes Once all changes to server controls are done, this event can be an opportunity to save control data in to view state.
9 Render Yes Yes Yes If you want to add some custom HTML to the output this is the place you can.
10 Unload Yes Yes Yes Any kind of clean up you would like to do here.

Image 10

About the Source Code

This source code shows how the complete ASP.NET request cycle fires. You can download it from here.

References

I am not so smart to write this article by myself ;-), lot of things I have plugged from the below articles.
